PT Smart Standard
PT Smart Underground Structure
Specifications
& Guidelines
PT Smart
BeltTrainer
12-3/8"
(310mm)
15-3/8"
(384mm)
B
B
C
D
D
19-1/2"
(488 mm)
A
5"
(125mm)
3"
(75mm)
1"
(25mm)
2"
(50mm)
3-1/8"
(79mm)
C
A
BELT WIDTH
ITEM
CODE
A
B
C
D
(vertical
adjustment)
in.
mm
18 450 77664 23-35"
(575-875mm)
10-23"
(250-575mm)
10"
(250mm)
0"-10"
(0-250mm)
24 600 77665 29-41"
(725-1025mm)
16-29"
(400-725mm)
30 750 77666 35-47"
(875-1175mm)
22-35"
(550-875mm)
36 900 77667 41-53"
(1025-1325mm)
28-41"
(700-1025mm)
42 1050 77668 47-59"
(1175-1475mm)
33-47"
(825-1175mm)
48 1200 77669 53-65"
(1325-1625mm)
40-53"
(1000-1325mm)
54 1350 77670 59-71"
(1475-1775mm)
46-59"
(1150-1475mm)
60 1500 77671 65-77"
(1625-1925mm)
52-65"
(1300-1625mm)
72 1800 77672 77-89"
(1925-2225mm)
64-77"
(1600-1925mm)
BELT WIDTH ITEM
CODE
A
B
C
D
in.
mm
30 750 77673 35-47"
(875-1175mm)
27-40"
(675-1000mm)
10"
(250mm)
2-3/4" to
13-1/4"
(69mm to
331mm)
36 900 77674 41-53"
(1025-1325mm)
33-46"
(825-1150mm)
42 1050 77675 47-59"
(1175-1475mm)
39-52"
(975-1300mm)
48 1200 77676 53-65"
(1025-1625mm)
45-58"
(1125-1450mm)
54 1350 77677 59-71"
(1475-1775mm)
51-64"
(1275-1600mm)
60 1500 77678 65-77"
(1625-1925mm)
57-70"
(1425-1750mm)
72 1800 77679 77-89"
(1925-2225mm)
69-82"
(1725-2050mm)
10-1/2"
(262mm)
2-1/4" to
12-3/4"
(56mm to
319mm)
5"
(125mm)
3"
(75mm)
1"
(25mm)
19-1/2"
(488 mm)
