DF-Series Pneumatic Couplings

Interchange Data:

Parker 20-Series Manual Interchange (F-Series)

Parker 30-Series Automatic Interchange (D-Series)

Foster 3, 4, 5, and 6 Series

Hansen 1000, 400, 500 (F-Series)

Hansen 3000, 4000, 5000, 6000 (D-Series)

Materials:

Machined components are manufactured using solid steel,

brass, or 303 stainless steel bar stock.

Stainless steel balls, retaining rings, and springs maximize

corrosion resistance and extend service life.

Steel componentry is plated using ROHS Compliant

Trivalent Chrome.

Automatic couplers constructed of brass with steel tubular

valve as standard (⅜" to ¾" couplers have steel prong

valves).

¼" manual couplers constructed of brass with steel sleeve

and steel tubular valve as standard.

⅜" and ½" manual couplers constructed of steel as standard

with steel tubular valve.

Seal Components:

Nitrile (Buna-N) seals are standard, providing a temperature

range of

-40°F

to

+250°F

(

-40°C

to +

121°C

).

Rated Pressure Charts:

Body

Size

D-Series Automatic Industrial Interchange (Connected)

Brass Coupler/Steel Plug

Brass Coupler/Plug

Steel Coupler/Plug

303 Stainless Coupler/Plug

Max. Working Burst

Max. Working Burst

Max. Working Burst

Max. Working Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

1/4"

500 35 16,000 1,100 300 20 16,000 1,100 -

-

-

-

500 35 26,000 1,795

3/8"

500 35 15,500 1,070 300 20 14,500 1,000 -

-

-

-

500 35 25,500 1,760

1/2"

500 35 14,000 965 300 20 10,500 725 -

-

-

-

500 35 20,500 1,415

3/4"

500 35 10,000 670 -

-

-

-

-

-

-

-

-

-

-

-

Body

Size

F-Series Manual Industrial Interchange (Connected)

Brass Coupler/Steel Plug

Brass Coupler/Plug

Steel Coupler/Plug

303 Stainless Coupler/Plug

Max. Working Burst

Max. Working Burst

Max. Working Burst

Max. Working Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

1/4"

500 35 9,000 620 300 20 8,500 586 500 35 6,500 448 500 35 11,500 795

3/8"

500 35 11,500 790 300 20 10,000 690 500 35 19,500 1,345 500 35 20,500 1,415

1/2"

-

-

-

-

-

-

-

-

500 35 15,500 1,070 500 35 15,000 1,035

Body

Size

Interchange Standards

Functional Parameters

U.S.

Military

U.S.

Government

International

Standards

ANSI/NFPA

Standards

Locking Ball

Quantity

Air

Inclusion

Fluid

Loss

Vacuum

Rating

Flow

ΔP=15 PSI

1/4"

MIL-C-4109F A-A-59439 ISO6150B T3.20.14-1990

6

N/A

N/A

N/R 27 CFM

3/8"

-

-

ISO6150B T3.20.14-1990

6

N/A

N/A

N/R 45 CFM

1/2"

MIL-C-4109F A-A-59439 ISO6150B T3.20.14-1990

6

N/A

N/A

N/R 91 CFM

3/4"

-

-

-

T3.20.14-1990

9

N/A

N/A

N/R 200 CFM

Technical Specifications:

List Price Seal Option Adders:

Body

Size

Seal Options

Valve Options

Sleeve Options

Treatments

FKM EPDM Unvalved Brass

303SS Flanged Sleeve-Lock Brass

303SS Oxy-Clean

Pre Add $ Pre Add $ Suf Add $ Suf Add $ Suf Add $ Suf Add $ Suf Add $ Suf Add $ Suf Add $ Suf Add $

1/4"

F-

$2.00

P-

$2.50

-E

-$.65

-BV

$.90

-SV

$.90

-FS

N/A

-LS

$5.00

-BS

$2.60

-XS

$7.60

-C1

$12.00

3/8"

F-

3.10

P-

N/A

-E

-2.70

-BV

2.90

-SV

2.90

-FS

N/A

-LS

6.00

-BS

N/A

-XS

15.50

-C1

12.00

1/2"

F-

4.40

P-

N/A

-E

-3.00

-BV

3.50

-SV

3.50

-FS

N/A

-LS

7.50

-BS

N/A

-XS

20.00

-C1

14.00

3/4"

F-

N/A

P-

N/A

-E

-3.80

-BV

N/A

-SV

N/A

-FS

N/A

-LS

8.90

-BS

std.

-XS

N/A

-C1

16.00
