11

DQC116

877.963.4966 •

dixonvalve.com

General Product Information

Fluid Compatibility Guide

The following chart is intended only as a guide in selecting various elastomers and metals for use with fluids to be

conveyed through Dixon Quick Disconnect Couplings. This list does not guarantee suitability for a particular application.

Final selection is dependent upon operating pressure, fluid and ambient temperature, concentration of media, duration of

exposure, environmental conditions, and frequency of connect and disconnect.

Material

Prefix Code

Trade Name

Availability

Range °C

Range °F

Buna-N

Standard

Nitrile

Stock

-40°C to +121°C -40°F to +250°F

Buna-N (MIL-H-5606 Fluids)

M-

Nitrile

3-5 Days

-54°C to +135°C -65°F to +275°F

Buna-N (Hydrocarbon Fuels)

JF-

Nitrile

3-5 Days

-54°C to +71°C -65°F to +160°F

Fluorocarbon Rubber

F-

FKM

3-5 Days

-29°C to +204°C -20°F to +400°F

Ethyl Propylene Diene Monomer

P-

EPDM

5-7 Days

-54°C to +149°C -65°F to +300°F

Neoprene

E-

Neoprene

7-10 Days

-43°C to +149°C -45°F to +300°F

Silicone

S-

Silicone

7-10 Days

-73°C to +177°C -100°F to +350°F

Fluorosilicone (FVMQ)

FS-

Silastic®

7-10 Days

-60°C to +180°C -76°F to +376°F

Urethane

U-

Urethane

7-10 Days

-40°C to +82°C -40°F to +180°F

Polyurethane

UP-

Polyurethane

7-10 Days

-54°C to +100°C -65°F to 212°F

PTFE Encapsulated Silicone

TS-

TES

7-10 Days

-73°C to +204°C -100°F to +400°F

PTFE Encapsulated Fluorocarbon

TF-

TEF

7-10 Days

-73°C to +204°C -100°F to +400°F

Perfluoroelastomer (Compound 1)

K4-

Kalrez

®

4079

5-7 Days

-20°C to +316°C -4°F to +600°F

Perfluoroelastomer (Compound 2)

K6-

Kalrez

®

6375

7-10 Days

-20°C to +275°C -4°F to +525°F

Perfluoroelastomer (Compound 3)

K7-

Kalrez

®

7075

7-10 Days

-20°C to +327°C -4°F to +620°F

Fluoroelastomer

H-

Aflas

®

7-10 Days

-5°C to +204°C +23°F to +400°F

Media Name

Suggested

Seal

Media Name

Suggested

Seal

Media Name

Suggested

Seal

Acetic Anhydride

P-

Freon, General

E-

Mineral Spirits

Standard

Acetone

P-

Ferric Hydroxide

Standard Nickel Acetate

P-

Acetylene

Standard Formaldehyde (50%)

P-

Nickel Suphate

P-

Air (To 200°F)

Standard Fuel Oils, General

Standard Nitrogen, Gas

Standard

Air (Above 200°F)

F-

Gasoline

Standard Nitrous Oxide

Standard

Alcohol, Ethyl

P-

Glycerine (Glycerol)

Standard Octane

F-

Alcohol, Methyl

Standard Glycols

P-

Oleum Spirits

Standard

Alkalies, General

Standard Helium

Standard OS45 and OS45-1

F-

Ammonia, Aqueous

P-

Heptane

Standard Oxygen, Non-Breathing F-

Ammonia, Gas

P-

Hexane

Standard Paint Thinner

F-

Ammonia, Anhydrous

P-

Hydraulic Oil, Aircraft

Standard Paraffin

Standard

Ammonia, Hydroxide

P-

Hydraulic Oil, Petroleum Standard Peanut Oil

Standard

Aroclor

F-

Hydraulic Oil, Phosphate P-

Pentane

Standard

Benzene (Benzol)

F-

Hydrogen Gas

Standard Perchloroethylene

F-

Bleach Solutions

P-

Hydrolube

Standard Phosphoric Acid (100%)

P-

Brake Fluid, Non-Petro P-

Isobutyl Alcohol

P-

Photographic Solutions P-

Bromine Gas

F-

Isopropyl Alcohol

F-

Potassium Acetate

P-

Butane

Standard Jet Fuel (to 160°F)

JF-

Propane

Standard

Butyl Alcohol

Standard Jet Fuel (above 160°F)

F-

Propylene

F-

Carbon Dioxide, Dry

Standard Kerosene

Standard Propylene Glycol

Standard

Carbon Dioxide, Wet

Standard Lindol

P-

Silicone Oil

Nitrile

Carbon Monoxide

Standard LP Gas

Standard Steam, General Service H-

Carbon Tetrachloride

F-

Magnesium Hydroxide F-

Stoddard Solvent

Standard

Cellulube

P-

Methane

Standard Sulphuric Acid (100%)

F-

Creosote

F-

Methanol

Standard Toluene

F-

Crude Oil

F-

Methyl Bromide

F-

Transmission Fluid (A)

Standard

Cutting Oil

Standard Methyl Ethyl Ketone (MEK) P-

Trichloroethylene

F-

Diesel Fuel

Standard MIL-F-81912 (JP-9)

P-

Turpentine

Standard

Diester Lubricants

F-

MIL-H-5606

M1-

Vegetable Oil

Standard

Ethane

Standard MIL-H-5806

Standard Water

Standard

Ethanol

Standard MIL-H-6083

Standard Water, Distilled

Standard

Ethyl Chloride

Standard MIL-H-7083

Standard Water, Dionized

Standard

Ethylene Glycol

P-

Mineral Oils

Standard Water, Sea

P-
