General Product Information

Installation of 'N' and 'P' Series Ferruled Hose Barbs

Note that the charts below are to be used only as a guide and not as a steadfast rule for every coupling application. In some

instances, alternative dies and crimped dimensions must be employed. Hoses, as well as couplings, react differently during

crimping. This is due to the fact that there are variances in hose constructions for hose with similar dimensions. Some variables

are: textile braid versus wire braid, hardwall versus softwall, presence or lack of internal spiral wire as well as differences in hose

covers. In addition, the outer diameter of the hose tends to fluctuate from end to end and production lot to production lot. With

this in mind, we suggest that you measure the hose OD and maintain accurate records for each coupling application.

Installation of Light Duty Ferrules

Hose

ID

Fractional

Hose OD

Decimal

Hose OD

'N' Crimp

Length

'N' Crimp

OD ±.005

'P' Crimp

Length

'P' Crimp

OD ±.005

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

1/2"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

54/64"

55/64"

56/64"

57/64"

58/64"

59/64"

60/64"

61/64"

62/64"

63/64"

1"

1-1/64"

1-2/64"

1-10/64"

1-11/64"

1-12/64"

1-13/64"

1-14/64"

1-15/64"

1-16/64"

1-17/64"

1-18/64"

1-19/64"

1-20/64"

1-21/64"

1-22/64"

0.844

0.859

0.875

0.891

0.906

0.922

0.938

0.953

0.969

0.984

1.000

1.016

1.031

1.156

1.171

1.187

1.203

1.218

1.234

1.250

1.265

1.281

1.296

1.312

1.328

1.343

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/8"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

0.917

0.929

0.942

0.954

0.987

0.980

0.992

1.005

1.018

1.030

1.043

1.056

1.068

1.220

1.235

1.244

1.260

1.270

1.285

1.295

1.310

1.320

1.335

1.345

1.360

1.370

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

1-1/4"

0.917

0.929

0.942

0.954

0.987

0.980

0.992

1.005

1.018

1.030

1.043

1.056

1.068

1.220

1.235

1.244

1.260

1.270

1.285

1.295

1.310

1.320

1.335

1.345

1.360

1.370

Hose

ID

Fractional

Hose OD

Decimal

Hose OD

Dixon™

Part #

Ferrule

Thickness

SMOD

%

Compression

Crimp

Diameter

1/2"

1/2"

1/2"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

3/4"

1"

1"

1"

1"

1"

1"

1"

1"

54/64"

55/64"

56/64"

1-5/64"

1-6/64"

1-7/64"

1-8/64"

1-9/64"

1-10/64"

1-11/64"

1-12/64"

1-13/64"

1-14/64"

1-15/64"

1-16/64"

1-25/64"

1-26/64"

1-27/64"

1-28/64"

1-29/64"

1-30/64"

1-31/64"

1-32/64"

0.8438

0.8594

0.8750

1.0781

1.0938

1.1094

1.1250

1.1406

1.1563

1.1719

1.1875

1.2031

1.2188

1.2344

1.2500

1.3906

1.4063

1.4219

1.4375

1.4531

1.4688

1.4844

1.5000

CCF0906

CCF0906

CCF0906

CCF1120

CCF1120

CCF1149

CCF1149

CCF1190

CCF1190

CCF1218

CCF1218

CCF1246

CCF1246

CCF1277

CCF1277

CCF1430

CCF1430

CCF1469

CCF1469

CCF1500

CCF1500

CCF1530

CCF1530

0.024

0.024

0.024

0.030

0.030

0.030

0.030

0.025

0.025

0.025

0.025

0.030

0.030

0.030

0.030

0.030

0.030

0.030

0.030

0.030

0.030

0.030

0.030

0.513

0.513

0.513

0.763

0.763

0.763

0.763

0.763

0.763

0.763

0.763

0.763

0.763

0.763

0.763

1.007

1.007

1.007

1.007

1.007

1.007

1.007

1.007

15

15

15

20

20

20

20

20

20

20

20

20

20

20

20

20

20

20

20

20

20

20

20

0.853

0.866

0.880

1.086

1.098

1.111

1.123

1.126

1.138

1.151

1.163

1.186

1.198

1.211

1.223

1.380

1.392

1.405

1.417

1.430

1.442

1.455

1.467

Be Safe When Installing Quick Couplings!
