General Product Information

It is important to be safe when installing quick disconnect couplings into a pneumatic circuit. Never install a

pneumatic coupling directly into an air tool, use a piece of hose that is at least 18" long, between the tool and the

coupling, to prevent damage to the coupling. To protect the operator, safety devices, such as a safety check valve

and safety cable should be installed in case there is a hose or coupling failure.

whip

hose

safety

check valve

safety

cable

Installation of Pneumatic Couplings
