V-Series Hydraulic Couplings

Body

Size

V-Series Snap-Tite H/IH Interchange Unvalved Nipple (Male Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/4"

V2M2-E 1/4" - 18 NPTF

steel

$7.33

1.52 38.6 0.69 17.5 5/8" 0.16 5 50

1/4"

V2M2-B-E 1/4" - 18 NPTF

brass

8.02

1.52 38.6 0.69 17.5 5/8" 0.16 5 50

1/4"

V2M2-SS-E 1/4" - 18 NPTF 316 stainless

23.75

1.52 38.6 0.69 17.5 5/8" 0.16 5 50

3/8"

V3M3-E 3/8" - 18 NPTF

steel

8.18

1.72 43.7 0.90 22.9 13-16" 0.11 5 50

3/8"

V3M3-B-E 3/8" - 18 NPTF

brass

9.81

1.72 43.7 0.90 22.9 13/16" 0.11 5 50

3/8"

V3M3-SS-E 3/8" - 18 NPTF 316 stainless

34.52

1.72 43.7 0.90 22.9 13/16" 0.11 5 50

1/2"

V4M4-E 1/2" - 14 NPTF

steel

9.72

1.80 45.7 1.10 27.9 1"

0.15 5 25

1/2"

V4M4-B-E 1/2" - 14 NPTF

brass

11.93

1.80 45.7 1.10 27.9 1"

0.15 5 25

1/2"

V4M4-SS-E 1/2" - 14 NPTF 316 stainless

43.07

1.80 45.7 1.10 27.9 1"

0.15 5 25

3/4"

V6M6-E 3/4" - 14 NPTF

steel

14.51

2.19 55.6 1.31 33.3 1-3/16" 0.30 5 20

3/4"

V6M6-B-E 3/4" - 14 NPTF

brass

24.04

2.19 55.6 1.31 33.3 1-3/16" 0.28 5 20

3/4"

V6M6-SS-E 3/4" - 14 NPTF 316 stainless

90.14

2.19 55.6 1.31 33.3 1-3/16" 0.28 5 20

1"

V8M8-E 1" - 11 1/2 NPTF

steel

29.88

2.31 58.7 1.65 41.9 1-1/2" 0.40 -

10

1"

V8M8-B-E 1" - 11 1/2 NPTF

brass

36.51

2.31 58.7 1.65 41.9 1-1/2" 0.40 -

10

1"

V8M8-SS-E 1" - 11 1/2 NPTF 316 stainless

142.99

2.31 58.7 1.65 41.9 1-1/2" 0.40 -

10

1-1/4"

V10M10-E 1-1/4" - 11 1/2 NPTF

steel

64.11

2.14 54.4 2.06 52.3 1-7/8" 0.83 -

10

1-1/4"

V10M10-SS-E 1-1/4" - 11 1/2 NPTF 316 stainless

227.97

2.14 54.4 2.06 52.3 1-7/8" 0.83 -

10

1-1/2"

V12M12-E 1-1/2" - 11 1/2 NPTF

steel

100.06

2.34 59.4 2.33 59.2 2-1/8" 1.08 -

5

1-1/2"

V12M12-SS-E 1-1/2" - 11 1/2 NPTF 316 stainless

328.62

2.34 59.4 2.33 59.2 2-1/8" 1.07 -

5

2"

V16M16-E 2" - 11 1/2 NPTF

steel

160.60

3.06 77.7 2.74 69.6 2-1/2" 1.44 -

5

2"

V16M16-SS-E 2" - 11 1/2 NPTF 316 stainless

454.03

3.06 77.7 2.74 69.6 2-1/2" 1.44 -

5

Body

Size

V-Series Dust Caps and Dust Plugs

Part Detail

List

Price

Package Qty

Coupler Dust Plug Nipple Dust Cap

Material

Bag

Box

1/4"

1HDP

V2DC

Nitrile

$3.16

10

50

3/8"

3VDP-V3DC combo dust cap/plug

Nitrile

3.51

10

50

1/2"

3KDP-K3DC combo dust cap/plug

Nitrile

3.51

10

50

3/4"

6VDP-V6DC combo dust cap/plug

Nitrile

8.52

5

25

1"

8VDP-V8DC combo dust cap/plug

Nitrile

10.53

5

25
