V-Series Hydraulic Couplings

Body

Size

V-Series Snap-Tite H/IH Interchange Valved Nipple (Male Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/4"

V2M1

1/8" - 27 NPTF

steel

$20.10

2.06 52.3 0.97 24.6 7/8" 0.15 5 50

1/4"

V2M2

1/4" - 18 NPTF

steel

18.08

2.06 52.3 0.97 24.6 7/8" 0.16 5 50

1/4"

V2M2-B 1/4" - 18 NPTF

brass

22.97

2.06 52.3 0.97 24.6 7/8" 0.16 5 50

1/4"

V2M2-SS 1/4" - 18 NPTF 316 stainless

86.84

2.06 52.3 0.97 24.6 7/8" 0.16 5 50

3/8"

V3M3

3/8" - 18 NPTF

steel

22.53

2.25 57.2 1.10 27.9 1"

0.21 5 50

3/8"

V3M3-B 3/8" - 18 NPTF

brass

31.88

2.25 57.2 1.10 27.9 1"

0.21 5 50

3/8"

V3M3-SS 3/8" - 18 NPTF 316 stainless

118.59

2.25 57.2 1.10 27.9 1"

0.21 5 50

1/2"

V4M4

1/2" - 14 NPTF

steel

26.96

2.40 61.0 1.31 33.3 1-3/16" 0.31 5 25

1/2"

V4M4-B 1/2" - 14 NPTF

brass

42.45

2.40 61.0 1.31 33.3 1-3/16" 0.31 5 25

1/2"

V4M4-SS 1/2" - 14 NPTF 316 stainless

181.16

2.40 61.0 1.31 33.3 1-3/16" 0.33 5 25

3/4"

V6M6

3/4" - 14 NPTF

steel

39.74

2.91 73.9 1.65 41.9 1-1/2" 0.62 5 20

3/4"

V6M6-B 3/4" - 14 NPTF

brass

58.94

2.91 73.9 1.65 41.9 1-1/2" 0.62 5 20

3/4"

V6M6-SS 3/4" - 14 NPTF 316 stainless

278.02

2.91 73.9 1.65 41.9 1-1/2" 0.63 5 20

1"

V8M8

1" - 11 1/2 NPTF

steel

71.82

3.22 81.8 2.06 52.3 1-7/8" 1.09 -

10

1"

V8M8-B 1" - 11 1/2 NPTF

brass

114.65

3.22 81.8 2.06 52.3 1-7/8" 1.09 -

10

1"

V8M8-SS 1" - 11 1/2 NPTF 316 stainless

366.04

3.22 81.8 2.06 52.3 1-7/8" 1.15 -

10

1-1/4"

V10M10 1-1/4" - 11 1/2 NPTF

steel

214.58

3.46 87.9 2.19 55.6 2"

1.31 -

10

1-1/4"

V10M10-B 1-1/4" - 11 1/2 NPTF

brass

276.11

3.46 87.9 2.19 55.6 2"

1.31 -

10

1-1/4"

V10M10-SS 1-1/4" - 11 1/2 NPTF 316 stainless

671.14

3.46 87.9 2.19 55.6 2"

1.35 -

10

1-1/2"

V12M12 1-1/2" - 11 1/2 NPTF

steel

275.83

3.85 97.8 2.74 69.6 2-1/2" 2.27 -

5

1-1/2"

V12M12-B 1-1/2" - 11 1/2 NPTF

brass

378.43

3.85 97.8 2.74 69.6 2-1/2" 2.27 -

5

1-1/2"

V12M12-SS 1-1/2" - 11 1/2 NPTF 316 stainless

935.09

3.85 97.8 2.74 69.6 2-1/2" 2.35 -

5

2"

V16M16 2" - 11 1/2 NPTF

steel

507.46

4.34 110.2 3.83 97.3 3-1/2" 4.77 -

5

2"

V16M16-B 2" - 11 1/2 NPTF

brass

745.66

4.34 110.2 3.83 97.3 3-1/2" 4.77 -

5

2"

V16M16-SS 2" - 11 1/2 NPTF 316 stainless

889.29

4.34 110.2 3.83 97.3 3-1/2" 4.79 -

5
