20

DQC116

877.963.4966 •

dixonvalve.com

DF-Series Pneumatic Couplings

Body

Size

DF-Series Industrial Interchange Nipple (Push-Loc Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Hose ID

Material

Inch mm Inch mm

Bag Box

1/4"

D2B2

1/4"

steel

$3.73

2.09 53.1 0.69 17.5 -

0.04 10 100

1/4"

D2B2-B

1/4"

brass

2.21

2.09 53.1 0.69 17.5 -

0.04 10 100

1/4"

D2B3

3/8"

steel

4.08

2.09 53.1 0.86 21.8 -

0.05 10 100

3/8"

D3B2

1/4"

steel

7.60

2.21 56.1 0.75 19.1 -

0.06 10 50

3/8"

D3B3

3/8"

steel

7.41

2.21 56.1 0.75 19.1 -

0.07 10 50

3/8"

D3B4

1/2"

steel

7.95

2.35 59.7 0.75 19.1 -

0.09 10 50

1/2"

D4B4

1/2"

steel

10.99

2.67 67.8 0.75 19.1 -

0.11 10 50

3/4"

D6B6

3/4"

steel

23.39

2.99 75.9 1.00 25.4 -

0.23 5 20

Body

Size

F-Series Manual Industrial Interchange Coupler (Push-Loc Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Hose ID

Material

Inch mm Inch mm

Bag Box

1/4"

2FB2-B

1/4"

brass

$11.25

2.49 63.2 0.88 22.4 3/4" 0.18 10 100

1/4"

2FB3-B

3/8'

brass

11.36

2.49 63.2 0.88 22.4 3/4" 0.19 10 100

3/8"

3FB2

1/4"

steel

26.24

2.80 71.1 1.06 26.9 7/8" 0.25 10 50

3/8"

3FB3

3/8"

steel

26.01

2.80 71.1 1.06 26.9 7/8" 0.27 10 50

3/8"

3FB4

1/2"

steel

26.62

2.80 71.1 1.06 26.9 7/8" 0.28 10 50

1/2"

4FB3

3/8"

steel

32.74

3.40 86.4 1.19 30.2 1"

0.40 5 30

1/2"

4FB4

1/2"

steel

31.87

3.40 86.4 1.19 30.2 1"

0.43 5 30

Body

Size

DF-Series Industrial Interchange Coupler (Reusable Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number Hose ID x OD Material

Inch mm Inch mm

Bag Box

1/4"

2DE2-B 1/4" x 1/2"

brass

$20.35

2.69 68.3 0.98 24.9 11/16" 0.38 10 100

1/4"

2DH2-B 1/4" x 5/8"

brass

20.35

2.79 70.9 0.98 24.9 11/16" 0.38 10 100

1/4"

2DK3-B 3/8" x 11/16"

brass

22.68

2.79 70.9 0.98 24.9 11/16" 0.39 10 100

1/4"

2DL3-B

3/8" x 3/4"

brass

20.35

2.85 72.4 0.98 24.9 11/16" 0.39 10 100

Body

Size

DF-Series Industrial Interchange Nipple (Reusable Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number Hose ID x OD Material

Inch mm Inch mm

Bag Box

1/4"

D2E2

1/4" x 1/2"

steel

$8.43

2.07 52.6 0.69 17.5 9/16" 0.10 10 100

1/4"

D2H2

1/4" x 5/8"

steel

8.43

2.16 54.9 0.81 20.6 9/16" 0.10 10 100

1/4"

D2K3

3/8" x 11/16"

steel

10.51

2.16 54.9 0.81 20.6 9/16" 0.12 10 100

1/4"

D2L3

3/8" x 3/4"

steel

10.93

2.18 55.4 0.95 24.1 9/16" 0.12 10 100
