155

DQC116

877.963.4966 •

dixonvalve.com

EA-Series Hydraulic Couplings

Body

Size

EA-Series Water-Blast Interchange Coupler (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/2"

4EAF3 3/8" - 18 NPTF steel

$125.17

2.20 55.9 1.62 41.1 1-1/4" 0.68 5 25

1/2"

4EAF4 1/2" - 14 NPTF steel

125.17

2.20 55.9 1.62 41.1 1-1/4" 0.65 5 25

Body

Size

EA-Series Water-Blast Interchange Nipple (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/2"

EA4F3 3/8" - 18 NPTF steel

$34.88

2.35 59.7 1.62 41.1 1-1/8" 0.38 5 25

1/2"

EA4F4 1/2" - 14 NPTF steel

34.88

2.35 59.7 1.62 41.1 1-1/8" 0.34 5 25

Body

Size

E-Series Water-Blast Interchange Coupler Seal Kits

Part Detail

List

Price

Seal Kit

Package Qty

Part Number Coupler Style Seal Material

Contents

Bag Box

1/2"

4EA-SKIT

all

Nitrile

$5.47

Body O-Ring and PTFE Back-up

25 200

1/2"

F-4EA-SKIT

all

FKM

6.46

Body O-Ring and PTFE Back-up

25 200

1/2"

P-4EA-SKIT

all

EPDM

6.46

Body O-Ring and PTFE Back-up

25 200

EA Profile

1/2"
