161

DQC116

877.963.4966 •

dixonvalve.com

CM-Series Hydraulic Couplings

Body

Size

CM-Series Industrial Mold Interchange Unvalved Coupler (45º Push-Loc Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Hose ID

Material

Inch mm Inch mm

Bag Box

1/4"

2CM4B2-B-E

1/4"

brass

$15.81

2.86 72.6 0.69 17.5 -

0.13 10 100

1/4"

2CM4B3-B-E

3/8"

brass

15.81

2.92 74.2 0.69 17.5 -

0.15 10 100

3/8"

3CM4B3-B-E

3/8"

brass

21.78

3.82 97.0 0.95 24.1 -

0.34 10 50

3/8"

3CM4B4-B-E

1/2"

brass

21.78

3.98 101.1 0.95 24.1 -

0.34 10 50

1/2"

4CM4B4-B-E

1/2"

brass

41.12

4.28 108.7 1.18 30.0 -

0.83 5 30

1/2"

4CM4B6-B-E

3/4"

brass

43.44

4.56 115.8 1.18 30.0 -

0.83 5 30

Body

Size

CM-Series Industrial Mold Interchange Valved Coupler (45º Push-Loc Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Hose ID

Material

Inch mm Inch mm

Bag Box

1/4"

2CM4B2-B

1/4"

brass

$18.86

2.86 72.6 0.69 17.5 -

0.14 10 100

1/4"

2CM4B3-B

3/8"

brass

18.86

2.92 74.2 0.69 17.5 -

0.17 10 100

3/8"

3CM4B3-B

3/8"

brass

28.53

3.82 97.0 0.95 24.1 -

0.36 10 50

3/8"

3CM4B4-B

1/2"

brass

28.53

3.98 101.1 0.95 24.1 -

0.40 10 50

Body

Size

CM-Series Industrial Mold Interchange Unvalved Coupler (90º Hose Barb)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Hose ID

Material

Inch mm Inch mm

Bag Box

1/4"

2CM9S2-B-E

1/4"

brass

$14.81

1.98 50.3 0.69 17.5 -

0.13 10 100

1/4"

2CM9S2.5-B-E 5/16"

brass

14.81

1.98 50.3 0.69 17.5 -

0.13 10 100

1/4"

2CM9S3-B-E

3/8"

brass

14.81

2.17 55.1 0.69 17.5 -

0.14 10 100

3/8"

3CM9S3-B-E

3/8"

brass

19.76

2.84 72.1 0.95 24.1 -

0.31 10 50

3/8"

3CM9S4-B-E

1/2"

brass

19.76

2.85 72.4 0.95 24.1 -

0.33 10 50

1/2"

4CM9S4-B-E

1/2"

brass

46.93

3.50 88.9 1.18 30.0 -

0.79 5 30

1/2"

4CM9S6-B-E

3/4"

brass

47.54

3.50 88.9 1.18 30.0 -

0.80 5 30
