126

DQC116

877.963.4966 •

dixonvalve.com

W-Series Hydraulic Couplings

Body

Size

W-Series Wingstyle Interchange Coupler (Female Threads)

Part Detail

List

Price

Length Maximum OD Flats

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

3/4"

6WF4-B 1/2" - 14 NPTF

brass

$79.57

2.73 69.3 4.09 103.9 1-5/32" 1.20 -

10

3/4"

6WBF4-B 1/2" - 14 BSPP

brass

74.26

2.73 69.3 4.09 103.9 1-5/32" 1.20 -

10

3/4"

6WF6-B 3/4" - 14 NPTF

brass

79.57

2.73 69.3 4.09 103.9 1-5/32" 1.20 -

10

3/4"

6WBF6-B 3/4" - 14 BSPP

brass

95.48

2.73 69.3 4.09 103.9 1-5/32" 1.20 -

10

1"

8WF8-B 1" - 11 1/2 NPTF

brass

97.60

3.33 84.6 4.49 114.0 1-15/32" 1.90 -

10

1"

8WF8

1" - 11 1/2 NPTF

steel

100.79

3.33 84.6 4.49 114.0 1-15/32" 1.95 -

10

1"

8WBF8-B 1" - 11 BSPP

brass

97.60

3.33 84.6 4.49 114.0 1-15/32" 1.90 -

10

1-1/4"

10WF10-B 1-1/4" - 11 1/2 NPTF

brass

178.23

3.64 92.5 5.27 133.9 1-25/32" 3.00 -

5

1-1/4"

10WBF10-B 1-1/4" - 11 BSPP

brass

188.49

3.64 92.5 5.27 133.9 1-25/32" 3.00 -

5

1-1/2"

12WF12-B 1-1/2" - 11 1/2 NPTF

brass

212.18

3.67 93.2 5.35 135.9 2-7/64" 3.60 -

5

1-1/2"

12WBF12-B 1-1/2" - 11 BSPP

brass

228.09

4.08 103.6 5.35 135.9 2-7/64" 3.60 -

5

Body

Size

W-Series Wingstyle Interchange Hex-Nut Coupler (Female Threads)

Part Detail

List

Price

Length Maximum OD Flats

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

3/4"

6WF4-B-HN 1/2" - 14 NPTF

brass

$79.57

2.73 69.3 1.92 48.8 1-5/32" 1.05 -

10

3/4"

6WBF4-B-HN 1/2" - 14 BSPP

brass

95.48

2.73 69.3 1.92 48.8 1-5/32" 1.05 -

10

3/4"

6WF6-B-HN 3/4" - 14 NPTF

brass

79.57

2.73 69.3 1.92 48.8 1-5/32" 1.05 -

10

3/4"

6WBF6-B-HN 3/4" - 14 BSPP

brass

95.48

2.73 69.3 1.92 48.8 1-5/32" 1.05 -

10

1"

8WF8-B-HN 1" - 11 1/2 NPTF

brass

97.60

3.33 84.6 2.33 59.2 1-15/32" 1.70 -

10

1"

8WF8-HN 1" - 11 1/2 NPTF

steel

113.52

3.33 84.6 2.33 59.2 1-15/32" 1.75

10

1"

8WBF8-B-HN 1" - 11 BSPP

brass

113.52

3.33 84.6 2.33 59.2 1-15/32" 1.70 -

10

1-1/4"

10WF10-B-HN 1-1/4" - 11 1/2 NPTF

brass

178.23

3.64 92.5 2.75 69.9 1-25/32" 2.70 -

5

1-1/4"

10WBF10-B-HN 1-1/4" - 11 BSPP

brass

188.49

3.64 92.5 2.75 69.9 1-25/32" 2.70 -

5

1-1/2"

12WF12-B-HN 1-1/2" - 11 1/2 NPTF

brass

212.18

3.67 93.2 3.01 76.5 2-7/64" 3.15 -

5

1-1/2"

12WBF12-B-HN 1-1/2" - 11 BSPP

brass

228.09

3.67 93.2 3.01 76.5 2-7/64" 3.15 -

5
