WS-Series Hydraulic Couplings

Interchange Data:

Snap-Tite 75-Series, Hydraulics Inc. Series-5TV, DNP VFF-

HD, Stucchi VOF, Faster OGV, Eaton FD85, Holmbury LC

Materials:

Machined components are manufactured using solid steel or

316 stainless steel bar stock.

Stainless steel retaining rings, and springs maximize

corrosion resistance and extend service life.

Steel componentry is plated using ROHS Compliant Zinc

Nickel for superior corrosion resistance.

Rugged high-strength steel sand-cast wing nut for threaded

connect and disconnect operation.

316 stainless steel nipple connection-threads are coated to

prevent galling during connection/disconnection.

Nitrile (Buna-N) seals are standard, providing a temperature

range of

-40°F

to

+250°F

(

-40°C

to

+121°C

).

PTFE anti-extrusion ring protects main coupling O-ring from

dynamic impulse pressure damage.

Main valve seal is 'housed' to improve seal integrity during

pressurized connection/disconnection.

Seal Components:

Rated Pressure Chart:

Body

Size

WS-Series High Pressure Wingstyle Interchange (Connected)

Steel Coupler/Plug

316 SS Coupler/Plug

Maximum Working

Burst

Maximum Working

Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

3/4"

5,000

345

32,800

2,200

3,000

200

20,000

1,400

1"

5,000

345

25,100

1,700

3,000

200

20,000

1,400

1-1/4"

5,000

345

25,100

1,700

3,000

200

15,000

1,000

1-1/2"

5,000

345

20,000

1,400

3,000

200

15,000

1,000

2"

5,000

345

15,000

1,000

3,000

200

15,000

1,000

Technical Specifications:

Body

Size

Interchange Standards

Functional Parameters

U.S.

Military

U.S.

Government

International

Standards

ANSI/NFPA

Standards

Locking

Mechanism

Air

Inclusion

Fluid

Loss

Vacuum

Inch HG

Flow

ΔP = 30 PSI

3/4"

-

-

-

-

Threaded 10cc

10cc

27.4

35 GPM

1"

-

-

-

-

Threaded 23cc

15cc

27.4

65 GPM

1-1/4"

-

-

-

-

Threaded 50cc

30cc

27.4 105 GPM

1-1/2"

-

-

-

-

Threaded 100cc

60cc

27.4 160 GPM

2"

-

-

-

-

Threaded 200cc

135cc

27.4 270 GPM

List Price Seal Option Adders:

Body

Size

Standard Seal Options

Standard Coupling Options

FKM EPDM Mil-Nitrile Fuel Nitrile Silicone Wrench Flats View Port

Oxy-Clean

Pre Add $ Pre Add $ Pre Add $ Pre Add $ Pre Add $ Suf

Add $ Suf

Add $ Suf

Add $

3/4"

F-

$6.16

P-

$6.16

M-

$6.16

JF-

$6.16

S-

$6.16

-WF

$34.00

-VP

$20.00

-C1

$20.00

1"

F-

7.70

P-

7.70

M-

7.70

JF-

7.70

S-

7.70

-WF

34.00

-VP

20.00

-C1

20.00

1-1/4"

F-

12.32

P-

12.32

M-

12.32

JF-

12.32

S-

12.32

-WF

34.00

-VP

20.00

-C1

22.00

1-1/2"

F-

15.40

P-

15.40

M-

15.40

JF-

15.40

S-

15.40

-WF

38.00

-VP

24.00

-C1

22.00

2"

F-

21.56

P-

21.56

M-

21.56

JF-

21.56

S-

21.56

-WF

38.00

-VP

28.00

-C1

26.00

Wrench flat option not available on 3/4" ORB configuration
