HT-Series ISO16028 Flushface Coupler Dust Plug

Part Detail

List

Price

Weight

Lb

Package Qty

Part Number

Body

Bag

Box

1/4"

2HTDP

Nitrile

$7.70

0.05

5

50

3/8"

3HTDP

Nitrile

8.58

0.05

5

50

1/2"

4HTDP

Nitrile

11.36

0.06

5

50

5/8"

5HTDP

Nitrile

13.37

0.07

5

50

3/4"

6HTDP

Nitrile

14.37

0.07

5

50

1"

8HTDP

Nitrile

16.49

0.15

5

50

Body

Size

HT-Series ISO16028 Flushface Nipple Dust Cap

Part Detail

List

Price

Weight

Lb

Package Qty

Part Number

Body

Bag

Box

1/4"

HT2DC

Nitrile

$7.70

0.04

5

50

3/8"

HT3DC

Nitrile

8.58

0.04

5

50

1/2"

HT4DC

Nitrile

11.36

0.04

5

50

5/8"

HT5DC

Nitrile

13.37

0.06

5

50

3/4"

HT6DC

Nitrile

14.37

0.06

5

50

1"

HT8DC

Nitrile

16.49

0.10

5

50

HT-Series Hydraulic Couplings

Using the Profile Layover to Select Proper Size

Using the Nipple Profile Dimensions to Select Proper Size

ISO16028

Body Size

Minimum Dimension

'X' Measurement

Maximum Dimension

'X' Measurement

1/4"

3/8"

1/2"

5/8"

3/4"

1"

0.634" (16.10 mm)

0.774" (19.66 mm)

0.963" (24.45 mm)

1.061" (26.95 mm)

1.176" (29.87 mm)

1.415" (35.94mm)

0.638" (16.20 mm)

0.779" (19.79 mm)

0.968" (24.58 mm)

1.066" (27.08 mm)

1.181" (30.00 mm)

1.420" (36.07 mm)

HT8 (1")

HT6 (3/4")

HT5 (5/8")

HT4 (1/2")

HT3 (3/8")

HT2 (1/4")
