HT-Series Hydraulic Couplings

Body

Size

HT-Series ISO16028 Flushface Interchange Coupler (Male Bulkhead Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/2"

4HTJB5 7/8" - 14 JIC BH steel

$101.93

4.38 111.3 1.54 39.1 1-5/16" 1.08 -

20

1/2"

4HTRB5 1" - 14 ORFS BH steel

101.93

4.37 111.0 1.54 39.1 1-5/16" 1.11 -

20

1/2"

4HTJB6 1-1/16" - 12 JIC BH steel

101.93

4.55 115.6 1.54 39.1 1-5/16" 1.22 -

20

Body

Size

HT-Series ISO16028 Flushface Interchange Nipple (Male Bulkhead Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/2"

HT4JB5 7/8" - 14 JIC BH steel

$63.71

3.99 101.3 1.44 36.6 1-5/16" 0.42 -

20

1/2"

HT4RB5 1" - 14 ORFS BH steel

63.71

3.98 101.1 1.44 36.6 1-5/16" 0.49 -

20

1/2"

HT4JB6 1-1/16" - 12 JIC BH steel

69.49

4.16 115.6 1.44 36.6 1-5/16" 0.54 -

20

Body

Size

HT-Series ISO16028 Flushface Interchange Coupler (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1-1/2"

12HTF12 1-1/2" - 11 1/2 NPT steel

1098.63

5.23 132.7 3.37 85.5 2-1/2" 7.6 -

1

1-1/2"

12HTBF12 1-1/2 - 11 BSPP

steel

1098.63

5.23 132.7 3.37 85.5 2-1/2" 7.6 -

1

1-1/2"

12HTOF12 1-7/8" - 12 ORB

steel

1153.56

5.23 132.7 3.37 85.5 2-1/2" 7.6 -

1

2"

16HTF16 2" - 11 1/2 NPTF

steel

1318.35

6.75 171.3 3.95 100.3 3-1/2" 13.8 -

1

2"

16HTBF16

2" - 11 BSPP

steel

1318.35

6.75 171.3 3.95 100.3 3-1/2" 13.8 -

1

2"

16HTOF16 2-1/2" - 12 ORB

steel

1384.26

6.75 171.3 3.95 100.3 3-1/2" 13.8 -

1

Body

Size

HT-Series ISO16028 Flushface Interchange Nipple (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1-1/2"

HT12F12 1-1/2" - 11 1/2 NPT steel

590.39

4.25 107.9 2.75 69.8 2-1/2" 3.5 -

1

1-1/2"

HT12BF12 1-1/2 - 11 BSPP

steel

590.39

4.25 107.9 2.75 69.8 2-1/2" 3.5 -

1

1-1/2"

HT12OF12 1-7/8" - 12 ORB

steel

619.91

4.25 107.9 2.75 69.8 2-1/2" 3.5 -

1

2"

HT16F16 2" - 11 1/2 NPTF

steel

708.46

4.62 117.3 3.29 83.5 3"

5.1 -

1

2"

HT16BF16

2" - 11 BSPP

steel

708.46

4.62 117.3 3.29 83.5 3"

5.1 -

1

2"

HT16OF16 2-1/2" - 12 ORB

steel

743.89

4.62 117.3 3.29 83.5 3"

5.1 -

1
