114

DQC116

877.963.4966 •

dixonvalve.com

ST-Series Hydraulic Couplings

List Price Option Adders:

Body

Size

Standard Seal Options

Kalrez

®

Seal Options

Sleeve Treatments

FKM EPDM Mil-Nitrile Fuel Nitrile 4079

6375

7075

Locking Oxy-Clean

Pre Add $ Pre Add $ Pre Add $ Pre Add $ Pre Add $ Pre Add $ Pre Add $ Suf Add $ Suf

Add $

1/4"

F-

$0.00

P-

$2.69

M-

$2.80

JF-

$2.75

K4-

POR

K6-

POR

K7-

POR

-LS

$3.90

-C1

$16.00

3/8"

F-

0.00

P-

4.48

M-

4.38

JF-

4.53

K4-

POR

K6-

POR

K7-

POR

-LS

4.50

-C1

16.00

1/2"

F-

0.00

P-

6.16

M-

5.49

JF-

5.65

K4-

POR

K6-

POR

K7-

POR

-LS

4.50

-C1

16.00

3/4"

F-

0.00

P-

8.90

M-

7.11

JF-

7.61

K4-

POR

K6-

POR

K7-

POR

-LS

11.50

-C1

19.00

1"

F-

0.00

P-

11.17

M-

9.06

JF-

9.22

K4-

POR

K6-

POR

K7-

POR

-LS

11.50

-C1

21.00

1"-V2

F-

0.00

P-

11.17

M-

9.06

JF-

9.22

K4-

POR

K6-

POR

K7-

POR

-LS

11.50

-C1

21.00

2"

F-

0.00

P-

21.19

M-

18.74

JF-

19.46

K4-

POR

K6-

POR

K7-

POR

-LS

14.40

-C1

24.00

Body

Size

ST-Series Snap-Tite 71-Series Interchange Coupler (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/4"

2STF2

1/4" - 18 NPTF

steel

$86.78

1.96 49.8 1.23 31.2 15/16" 0.25 5 25

1/4"

2STF2-SS 1/4" - 18 NPTF 316 stainless

246.02

1.96 49.8 1.23 31.2 15/16" 0.26 5 25

1/4"

2STBF2

1/4" - 19 BSPP

steel

86.78

1.96 49.8 1.23 31.2 15/16" 0.25 5 25

1/4"

2STBF2-SS 1/4" - 19 BSPP 316 stainless

246.02

1.96 49.8 1.23 31.2 15/16" 0.26 5 25

3/8"

3STF2

1/4" - 18 NPTF

steel

82.12

2.36 59.9 1.6 40.6 1-3/16" 0.38 5 25

3/8"

3STF3

3/8" - 18 NPTF

steel

82.12

2.36 59.9 1.6 40.6 1-3/16" 0.37 5 25

3/8"

3STF3-SS 3/8" - 18 NPTF 316 stainless

293.54

2.36 59.9 1.6 40.6 1-3/16" 0.38 5 25

3/8"

3STBF3

3/8" - 19 BSPP

steel

82.12

2.36 59.9 1.6 40.6 1-3/16" 0.37 5 25

3/8"

3STBF3-SS 3/8" - 19 BSPP 316 stainless

293.54

2.36 59.9 1.6 40.6 1-3/16" 0.38 5 25

3/8"

3STF4

1/2" - 14 NPTF

steel

82.12

2.36 59.9 1.6 40.6 1-3/16" 0.36 5 25

3/8"

3STF4-SS 1/2" - 14 NPTF 316 stainless

293.54

2.36 59.9 1.6 40.6 1-3/16" 0.37 5 25

3/8"

3STBF4

1/2" - 14 BSPP

steel

82.12

2.36 59.9 1.6 40.6 1-3/16" 0.36 5 25

3/8"

3STBF4-SS 1/2" - 14 BSPP 316 stainless

293.54

2.36 59.9 1.6 40.6 1-3/16" 0.37 5 25

1/2"

4STF4

1/2" - 14 NPTF

steel

100.45

2.77 70.4 1.98 50.3 1-1/2" 0.47 -

20

1/2"

4STF4-SS 1/2" - 14 NPTF 316 stainless

384.51

2.77 70.4 1.98 50.3 1-1/2" 0.49 -

20

1/2"

4STBF4

1/2" - 14 BSPP

steel

100.45

2.77 70.4 1.98 50.3 1-1/2" 0.47 -

20

1/2"

4STBF4-SS 1/2" - 14 BSPP 316 stainless

384.51

2.77 70.4 1.98 50.3 1-1/2" 0.49 -

20

1/2"

4STOF4

3/4" - 16 ORB

steel

105.03

2.77 70.4 1.98 50.3 1-1/2" 0.49 -

20

3/4"

6STF6

3/4" - 14 NPTF

steel

139.77

3.03 77.0 2.35 59.7 1-3/4" 1.98 -

10

3/4"

6STF6-SS 3/4" - 14 NPTF 316 stainless

668.69

3.03 77.0 2.35 59.7 1-3/4" 2.05 -

10

3/4"

6STBF6

3/4" - 14 BSPP

steel

139.77

3.03 77.0 2.351 59.7 1-3/4" 1.98 -

10

3/4"

6STBF6-SS 3/4" - 14 BSPP 316 stainless

668.69

3.03 77.0 2.35 59.7 1-3/4" 2.05 -

10

3/4"

6STOF6 1-1/16" - 12 ORB

steel

151.92

3.03 77.0 2.35 59.7 1-3/4" 1.89 -

10

1"

8STF8

1" - 11 1/2 NPTF

steel

252.80

3.33 84.6 2.73 69.3 2"

2.78 -

5

1"

8STF8-SS 1" - 11 1/2 NPTF 316 stainless

1052.58

3.33 84.6 1.55 39.3 2"

2.83 -

5

1"

8STBF8

1" - 11 BSPP

steel

252.80

3.33 84.6 2.73 69.3 2"

2.78 -

5

1"

8STBF8-SS 1" - 11 BSPP 316 stainless

1052.58

3.33 84.6 2.73 69.3 2"

2.83 -

5

1"

8STOF8 1-5/16" - 12 ORB

steel

278.40

3.33 84.6 2.73 69.3 2"

2.71 -

5

1"

8STF10 1-1/4" - 11 1/2 NPTF

steel

295.34

3.67 93.2 2.73 69.3 2"

2.84 -

5

1"

8STF10-SS 1-1/4" - 11 1/2 NPTF 316 stainless

1263.10

3.67 93.2 2.73 69.3 2"

2.90 -

5

1"

8STBF10 1-1/4" - 11 BSPP

steel

295.34

3.67 93.2 2.73 69.3 2"

2.84 -

5

1"

8STBF10-SS 1-1/4" - 11 BSPP 316 stainless

1263.10

3.67 93.2 2.73 69.3 2"

2.90 -

5

1"

8STOF10 1-5/8" - 12 ORB

steel

303.67

3.67 93.2 2.73 69.3 2"

2.79 -

5
