112

DQC116

877.963.4966 •

dixonvalve.com

HTE-Series Hydraulic Couplings

Body

Size

HTE-Series ISO 16028 Connect Under Pressure Flush Face Nipple (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

mm

Weight

Lb

Package

Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

3/8"

HTE3F4

1/2"-14 NPTF

steel

$71.50

3.25 82.6 1.30 33.0 1-1/8" 0.95 -

10

3/8

"

HTE3BF4

1/2"-14 BSPP

steel

75.65

3.25 82.6 1.30 33.0 1-1/8" 0.95

10

3/8"

HTE3OF4

3/4"-16 ORB

steel

73.08

3.25 82.6 1.30 33.0 1-1/8" 0.95 -

10

1/2"

HTE4F4

1/2"-14 NPTF

steel

84.81

3.40 86.4 1.30 33.0 1-3/16" 1.07 -

10

1/2"

HTE4BF4

1/2"-14 BSPP

steel

88.97

3.40 86.4 1.30 33.0 1-3/16" 1.07

10

1/2"

HTE4OF4

3/4"-16 ORB

steel

88.08

3.40 86.4 1.30 33.0 1-3/16" 1.07

10

1/2"

HTE4OF5

7/8"-14 ORB

steel

88.08

3.40 86.4 1.30 33.0 1-1/2" 1.10

10

1/2"

HTE4F6

3/4"-14 NPTF

steel

86.39

3.60 91.4 1.65 41.9 1-1/2" 1.10

10

1/2"

HTE4BF6

3/4"-14 BPSS

steel

89.33

3.60 91.4 1.65 41.9 1-1/2" 1.10

10

1/2"

HTE4OF6 1-1/16"-12 ORB

steel

88.08

3.60 91.4 1.65 41.9 1-1/2" 1.10 -

10

5/8"

HTE5OF5

7/8"-14 ORB

steel

146.47

3.75 95.3 1.65 41.9 1-1/2" 1.55 -

10

5/8"

HTE5F6

3/4"-14 NPTF

steel

145.00

3.75 95.3 1.65 41.9 1-1/2" 1.55

10

5/8"

HTE5BF6

3/4"-14 BSPP

steel

150.68

3.75 95.3 1.65 41.9 1-1/2" 1.55

10

5/8"

HTE5OF6 1-1/16"-12 ORB

steel

146.47

3.75 95.3 1.65 41.9 1-1/2" 1.75 -

10

3/4"

HTE6F6

3/4"-14 NPTF

steel

171.63

4.25 108.0 1.96 49.8 1-1/2" 1.80 -

5

3/4"

HTE6BF6

3/4"-14 BSPP

steel

171.63

4.25 108.0 1.96 49.8 1-1/2" 1.80

5

3/4"

HTE6OF6 1-1/16"-12 ORB

steel

173.09

4.25 108.0 1.96 49.8 1-1/2" 1.80

5

3/4"

HTE6F8

1"-11 1/2 NPTF

steel

171.63

4.40 111.8 1.96 49.8 1-3/4" 2.10

5

3/4"

HTE6BF8

1"-11 BSPP

steel

182.97

4.40 111.8 1.96 49.8 1-3/4" 2.10

5

3/4"

HTE6OF8 1-5/16"-12 ORB

steel

173.09

4.40 111.8 1.96 49.8 1-3/4" 2.10 -

5

1"

HTE8F8

1"-11 1/2 NPTF

steel

370.17

4.88 124.0 1.96 49.8 1-3/4" 2.15 -

5

1"

HTE8BF8

1"-11 BSPP

steel

370.17

4.88 124.0 1.96 49.8 1-3/4" 2.15

5

1"

HTE8OF8 1-5/16"-12 ORB

steel

370.17

4.88 124.0 1.96 49.8 1-3/4" 2.15

5

1"

HTE8F10 1-1/4"-11 1/2 NPTF

steel

370.17

5.00 127.0 2.47 62.7 2-3/16" 2.40

5

1"

HTE8BF10 1-1/4"-11 BSPP

steel

370.17

5.00 127.0 2.47 62.7 2-3/16" 2.40

5

1"

HTE8OF10 1-5/8"-12 ORB

steel

370.17

5.00 127.0 2.47 62.7 2-3/16" 2.40 -

5

For use with HT-Series Couplers
