Product Ordering
Information
Flex-Lag
®
Full Ceramic Pulley Lagging
BELT WIDTH / CERAMIC STRIP LENGTH
MAXIMUM PULLEY FACE WIDTH / OVERALL STRI
P L
ENGTH
Ordering Number Key:
N
- SBR,
FR
- FRAS
FRAS (Fire Resistant Anti Static) MSHA Certification # - MSHA NO. IC-190
Special Offerings
PRODUCT
PRICE COMPARED TO
NATURAL RUBBER
15mm Thickness
+5%
20mm Thickness
+7 1/2%
25mm Thickness
+15%
Specifications:
Temperature Rating
5°F to 185° F (-15° C to 85° C)
Ceramic Compound
Aluminum Oxide (Al
2
0
3
)
Rubber Compound
SBR (Styrene-Butadiene-
Rubber)
Ceramic Hardness
83 HRA Rockwell
Hardness Scale A
Rubber Hardness
68 ± 3 Shore A
Shaded items are made to order.
Lead time: 8 -10 weeks
Strip Selection Chart
Pulley Diameter
Strips
Req’d
Pulley Diameter
Strips
Req’d
in.
mm
in.
mm
12.6-15.0 320-381
6
42.6-45.0 1083-1145
18
15.1-17.5 382-445
7
45.1-47.5 1146-1210
19
17.6-20.0 446-510
8
47.6-50.1 1211-1273
20
20.1-22.5 511-573
9
50.2-52.6 1274-1336
21
22.6-25.0 574-636
10
52.7-55.1 1337-1400
22
25.1-27.5 637-700
11
55.2-57.6 1403-1463
23
27.6-30.0 701-764
12
57.7-60.1 1466-1527
24
30.1-32.5 765-827
13
60.2-62.6 1529-1590
25
32.6-35.0 828-891
14
62.7-65.1 1593-1654
26
35.1-37.5 892-955
15
65.2-67.6 1656-1717
27
37.6-40.0 956-1018
16
67.7-70.1 1720-1781
28
40.1-42.5 1019-1082
17
70.2-72.6 1783-1844
29
P R O D U C T H A N D B O O K
Flex-Lag
®
Full Ceramic Lagging - SBR Rubber
THICKNESS BELT WIDTH CERAMIC LENGTH STRIP LENGTH
DIMPLED TILE
SMOOTH TILE
in.
mm in.
mm in.
mm in.
mm ORDERING NUMBER ITEM CODE ORDERING NUMBER ITEM CODE
1/2 12 18 450 18 1/2
460
34
860
CLN460/18.4-12
71111
CLN460/18.4-12S
79383
1/2 12 24 600
24
600
40 1000
CLN600/24-12
71112
CLN600/24-12S
79384
1/2 12 30 750 30 1/2
760
46 1160
CLN760/30.4-12
71113
CLN760/30.4-12S
79385
1/2 12 36 900
36
900
52 1300
CLN900/36-12
71115
CLN900/36-12S
79387
1/2 12 42 1050 42 1/2 1060
60 1500 CLN1060/42.4-12
71116
CLN1060/42.4-12S
79388
1/2 12 48 1200
48
1200
64 1600
CLN1200/48-12
71039
CLN1200/48-12S
79389
1/2 12 54 1350 54 1/2 1360
72 1800 CLN1360/54.4-12
71126
CLN1360/54.4-12S
79390
1/2 12 60 1500 60 3/4 1520
80 2000 CLN1520/60.8-12
71127
CLN1520/60.8-12S
79392
1/2 12 72 1800
72
1800
92 2300
CLN1800/72-12
71042
CLN1800/72-12S
79395
1/2 12 84 2100
84
2100 104 2600
CLN2100/84-12
71044
CLN2100/84-12S
79398
Flex-Lag
®
Full Ceramic Lagging - FRAS Rubber
THICKNESS BELT WIDTH CERAMIC LENGTH STRIP LENGTH
DIMPLED TILE
SMOOTH TILE
in.
mm in.
mm in.
mm in.
mm ORDERING NUMBER ITEM CODE ORDERING NUMBER ITEM CODE
1/2 12 18 450 18 1/2 460
34
860
CLFR460/18.4-12
71118
CLFR460/18.4-12S
79406
1/2 12 24 600
24
600
40 1000
CLFR600/24-12
71119
CLFR600/24-12S
79407
1/2 12 30 750 30 1/2 760
46 1160
CLFR760/30.4-12
71120
CLFR760/30.4-12S
79408
1/2 12 36 900
36
900
52 1300
CLFR900/36-12
71122
CLFR900/36-12S
79410
1/2 12 42 1050 42 1/2 1060
60 1500 CLFR1060/42.4-12
71123
CLFR1060/42.4-12S
79411
1/2 12 48 1200 48
1200
64 1600
CLFR1200/48-12
71005
CLFR1200/48-12S
79412
1/2 12 54 1350 54 1/2 1360
72 1800 CLFR1360/54.4-12
A1636
CLFR1360/54.4-12S
79413
1/2 12 60 1500 60 3/4 1520
80 2000 CLFR1520/60.8-12
71009
CLFR1520/60.8-12S
79415
1/2 12 72 1800 72
1800
92 2300
CLFR1800/72-12
71079
CLFR1800/72-12S
79418
1/2 12 84 2100 84
2100 104 2600
CLFR2100/84-12
71082
CLFR2100/84-12S
79421
