• phone: 1-630-971-0150 147
Application Guidelines
• Belt Splice.................................. Mechanically Fastened/Vulcanized
• Belt Speed.................................. 1000 FPM (5M/sec) for V-Plow; 700 FPM (3.5M/sec) for Diagonal Plow
• Belt Direction............................. One Way
V-Plow & Diagonal Plow
Blade Specifications
Diagonal Plow
Belt Width Specifications
Use next larger size for belt widths between
ranges.
V-Plow
Belt Width Specifications
Use next larger size for belt widths between
ranges.
Specifications
& Guidelines
V-Plow & Diagonal Plow
SIZE
BELT WIDTH
(Min-Max)
in. mm
Extra Small 18-24 450-600
Small 30-36 750-900
Medium 42-48 1050-1200
Large 54-60 1350-1500
72" 72 1800
84" 84 2100
96" 96 2400
SIZE
BELT WIDTH
(Min-Max)
in. mm
Small 18-30 450-750
Medium 36-42 900-1050
Large 48-60 1200-1500
Extra Large 72-84 1800-2100
Material UHMWPE
Durometer 67-D
Working Temperature
°F -40° to 160°
°C -40° to 71°
Grease & Chemical
Resistance Excellent
Sticky Material
Performance Excellent
