105 / 206
www.flexco.com
• phone: 1-630-971-0150
105
Product Notes:
• Patent-pending Enhanced Service Advantage Cartridge
™
allows for easy removal in even the dirtiest conditions.
• Heavy-duty design to deliver maximum cleaning efficiency on the most demanding, abusive beltlines.
• Pole Length: Belt width plus 54" (1350mm) (single cartridge cleaners); Belt width plus 60” (1500mm) (dual cartridge cleaners).
• Patented PowerFlex
™
cushion design to maintain continuous blade-to-belt contact and quick relief from passing mechanical splices.
• C-Tips are for mechanically fastened or vulcanized belts. V-Tips are for vulcanized belts only.
• Visual Blade Tension Check: Measure the tension spring and refer to Spring Length Chart on mounting base for the correct length
for best cleaning performance.
• Tensioner mounting brackets included for fast and easy installation.
• Cartridge Removal Kit included for easy removal of the cartridge.
Product Ordering
Information
MHS ESAC
HD Secondary Cleaner
with Enhanced Service Advantage Cartridge
MHS ESAC Single Cartridge
MHS 2ESAC Dual Cartridge
Tips Required per Cleaner Size
in.
24 30 36 42 48 54 60 72 84 96 120
mm 600 750 900 1050 1200 1350 1500 1800 2100 2400 3000
C-Tips or V-Tips
Required
4 5 6 7 8 9 10 12 14 16 20
U.S. Patent No. 7,987,966; Patent Pending
Shaded items are made to order.
Lead time: 15 working days
P R O D U C T H A N D B O O K
Lead time: 1 working day
*NOTE: V-Tips can be used ONLY on vulcanized belts.
Lead time: 1 working day
Lead time: 1 working day
Replacement Tips
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
ICT6
74535 0.7
RSA150
73628 1.3
MHS ESAC Secondary with C-Tips
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
MHS-24-ESAC 77840 195.0
30
750
MHS-30-ESAC 77841 206.5
36
900
MHS-36-ESAC 77842 218.5
42
1050
MHS-42-ESAC 77843 230.1
48
1200
MHS-48-ESAC 77844 241.6
54
1350
MHS-54-ESAC 77845 253.2
60
1500
MHS-60-ESAC 77846 264.9
72
1800
MHS-72-ESAC 77847 288.4
60
1500
MHS-60-2ESAC 77848 309.1
72
1800
MHS-72-2ESAC 77849 332.9
84
2100
MHS-84-2ESAC 77850 356.6
96
2400
MHS-96-2ESAC 77851 381.1
120
3000 MHS-120-2ESAC 77852 432.5
MHS ESAC Secondary with V-Tips
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
MHS-24V-ESAC 77853 195.0
30
750
MHS-30V-ESAC 77854 206.5
36
900
MHS-36V-ESAC 77855 218.5
42
1050
MHS-42V-ESAC 77856 230.1
48
1200
MHS-48V-ESAC 77857 241.6
54
1350
MHS-54V-ESAC 77858 253.2
60
1500
MHS-60V-ESAC 77859 264.9
72
1800
MHS-72V-ESAC 77860 288.4
60
1500 MHS-60V-2ESAC 77861 309.1
72
1800 MHS-72V-2ESAC 77862 332.9
84
2100 MHS-84V-2ESAC 77863 356.6
96
2400 MHS-96V-2ESAC 77864 381.1
120
3000 MHS-120V-2ESAC 77865 432.5
Lead time: 1 working day
Replacement Shields
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
PFS-ESAC 79073
.5
PFRS
76622
.4
