100
Replacement
Parts List
P-Type
®
ESAC
Secondary Cleaner
with Enhanced Service Advantage Cartridge
Shaded items are made to order.
Lead time: 15 working days
4a
4b
15
Tip Alignment Tool
for Dual Cartridge Cleaners
14
4
2
2a
5
12
13
11
10
9
8
8
6
3
3a
1
1a
7
Replacement Parts
P R O D U C T H A N D B O O K
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
ESAC Cartridge Pole 24"
SACPL-24/600 77887 65.4
ESAC Cartridge Pole 30"
SACPL-30/750 77888 71.2
ESAC Cartridge Pole 36"
SACPL-36/900 77889 77.1
ESAC Cartridge Pole 42"
SACPL-42/1050 77890 82.9
ESAC Cartridge Pole 48"
SACPL-48/1200 77891 88.8
ESAC Cartridge Pole 54"
SACPL-54/1350 77892 94.6
ESAC Cartridge Pole 60"
SACPL-60/1500 77893 100.5
ESAC Cartridge Pole 72"
SACPL-72/1800 77894 112.2
ESAC Cartridge Center Pole 60" (Dual)
SACPL2-60/1500 77895 77.3
ESAC Cartridge Center Pole 72" (Dual)
SACPL2-72/1800 77896 89.5
ESAC Cartridge Center Pole 84" (Dual)
SACPL2-84/2100 77897 101.8
ESAC Cartridge Center Pole 96" (Dual)
SACPL2-96/2400 77898 114.1
ESAC Cartridge Center Pole 120" (Dual)
SACPL2-120/3000 77899 142.3
1a
Extender Pole
(for use with Dual Cartridge Center Pole)
MHP-EP
76392 54.0
2
ESAC Cartridge 24”
CART-24/600 77900 3.5
ESAC Cartridge 30"
CART-30/750 77901 4.3
ESAC Cartridge 36"
CART-36/900 77902 5.1
ESAC Cartridge 42"
CART-42/1050 77903 5.9
ESAC Cartridge 48"
CART-48/1200 77904 6.7
ESAC Cartridge 54"
CART-54/1350 77905 7.4
ESAC Cartridge 60"
CART-60/1500 77906 8.4
ESAC Cartridge 72"
CART-72/1800 77907 10.0
ESAC Cartridge 60" (Dual)
CART2-60/1500 77908 8.6
ESAC Cartridge 72" (Dual)
CART2-72/1800 77909 10.2
ESAC Cartridge 84" (Dual)
CART2-84/2100 77910 11.7
ESAC Cartridge 96" (Dual)
CART2-96/2400 77911 13.3
ESAC Cartridge 120" (Dual)
CART2-120/3000 77912 16.8
2a
ESAC Cartridge P-Type Adapter Plate 24"
PCAP-24/600 77913 4.7
ESAC Cartridge P-Type Adapter Plate 30" §
PCAP-30/750 77914 6.1
ESAC Cartridge P-Type Adapter Plate 36" §
PCAP-36/900 77915 7.2
ESAC Cartridge P-Type Adapter Plate 42" §
PCAP-42/1050 77916 8.6
ESAC Cartridge P-Type Adapter Plate 48" §
PCAP-48/1200 77917 9.8
ESAC Cartridge P-Type Adapter Plate 54"
PCAP-54/1350 77918 11.1
ESAC Cartridge P-Type Adapter Plate 60" §
PCAP-60/1500 77919 12.3
ESAC Cartridge P-Type Adapter Plate 72"
PCAP-72/1800 77920 14.8
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
3 C-Tip*
ICT6
74535 0.7
3a P V-Tip*
(for vulcanized belts only)
PSA150 73156 1.0
4 P2 C-Tip Cushion*
PHA 73626 2.0
4a P Cushion SS Neoprene*
(oil resistant)
PSSC 77045 3.5
4b P Cushion Neoprene*
(oil resistant)
PNC 74984 3.5
5 Adjusting Bracket Kit*
(1 ea.)
PAB 75513 1.5
6 HD Pole Clamp Kit Left*
(1 ea.) (incl. item 8)
CCKHDL 79225 8.7
7 HD Pole Clamp Kit Right*
(1 ea.) (incl. item 8)
CCKHDR 79229 8.7
8 HD Cradle Clamp Top Strap
(1 ea.)
for use with L or R HD Pole Clamp Kit
CCKHDTS 79233 1.7
9 Mounting Bracket Kit
(1 Right and 1 Left)
EZS2MBK 75666 13.0
-
HD Cradle Clamp Mounting Kit*
(incl. 2 items 5; 1 ea. items 6, 7 & 9)
CCMKHD 78920 36.7
10 ESAC Removal Knuckle
SACRKN 77882 3.2
11 ESAC Removal Handle
SACRH 77883 3.0
12 ESAC Handle Lock Plate
SACRHL 77884 1.7
13 Knuckle Retainer Pin
SACKRP 77885 0.2
14 SAC Hitch Pin
SACHP2 77768 0.9
-
ESAC Removal Kit
(includes 1 ea. items 10-14)
SACRKT 77886 9.0
15 ESAC Cartridge Tip Alignment Tool (Dual)
SAC2-TIP-TL 77866 2.5
*Hardware Included
Lead Time: 1 working day
