101
Replacement Tips
Tips Required Per Cleaner Size
R-Type ESAC Secondary with C-Tips
R-Type ESAC Secondary with V-Tips*
Product Notes:
• Patent-pending Enhanced Service Advantage Cartridge
™
allows for easy removal in even the dirtiest conditions.
• Pole Length: Belt width plus 54" (1350mm) (single cartridge cleaners); Belt width plus 60” (1500mm) (dual cartridge cleaners).
• Two-way cushions allow cleaning in both directions.
• C-Tips are for mechanically fastened or vulcanized belts. V-Tips are for vulcanized belts only.
• Tensioner mounting brackets included for fast and easy installation.
• Cartridge Removal Kit included for easy removal of the cartridge.
Product Ordering
Information
R-Type
®
ESAC
Secondary Cleaner
with Enhanced Service Advantage Cartridge
in.
24 30 36 42 48 54 60 72 84 96 120
mm 600 750 900 1050 1200 1350 1500 1800 2100 2400 3000
C-Tips or V-Tips
Required
4 5 6 7 8 9 10 12 14 16 20
U.S. Patent No. 7,987,966; Patent Pending
R-Type ESAC Single Cartridge
R-Type 2ESAC Dual Cartridge
Shaded items are made to order.
Lead time: 15 working days
P R O D U C T H A N D B O O K
Lead time: 1 working day
*NOTE: V-Tips can be used ONLY on vulcanized belts.
Lead time: 1 working day
Lead time: 1 working day
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
ICT6
74535 0.7
RSA150
73628 1.3
CLEANER COMPLETE
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
RC24-ESAC 77968 133.7
30
750
RC30-ESAC 77969 146.0
36
900
RC36-ESAC 77970 158.4
42
1050
RC42-ESAC 77971 170.7
48
1200
RC48-ESAC 77972 183.0
54
1350
RC54-ESAC 77973 195.3
60
1500
RC60-ESAC 77974 207.8
72
1800
RC72-ESAC 77975 232.4
60
1500
RC60-2ESAC 77976 237.0
72
1800
RC72-2ESAC 77977 259.4
84
2100
RC84-2ESAC 77978 281.8
96
2400
RC96-2ESAC 77979 304.2
120 3000 RC120-2ESAC 77980 354.0
CLEANER COMPLETE
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
RV24-ESAC
77994 133.7
30
750
RV30-ESAC
77995 146.0
36
900
RV36-ESAC
77996 158.4
42
1050
RV42-ESAC
77997 170.7
48
1200
RV48-ESAC
77998 183.0
54
1350
RV54-ESAC
77999 195.3
60
1500
RV60-ESAC
78000 207.8
72
1800
RV72-ESAC
78001 232.4
60
1500
RV60-2ESAC 78002 237.0
72
1800
RV72-2ESAC 78003 259.4
84
2100
RV84-2ESAC 78004 281.8
96
2400
RV96-2ESAC 78005 304.2
120 3000
RV120-2ESAC 78006 354.0
