V-Series Hydraulic Couplings

Body

Size

Interchange Standards

Functional Parameters

U.S. Military

International

Standards

ANSI/NFPA

Standards

Locking Ball

Quantity

Air

Inclusion

Fluid

Loss

Vacuum

Inch HG

Flow

ΔP = 22 PSI

1/4"

MIL-C-51234

-

-

6

2.0cc

0.2cc

26.7 5.5 GPM

3/8"

MIL-C-51234

-

-

6

3.5cc

3.2cc

26.7 9.5 GPM

1/2"

MIL-C-51234

-

-

9

4.0cc

4.0cc

26.7

13 GPM

3/4"

MIL-C-51234

-

-

9

14.0cc

14.0cc

26.7

30 GPM

1"

MIL-C-51234

-

-

12

21.0cc

20.0cc

26.7

48 GPM

1-1/4"

MIL-C-51234

-

-

12

45.0cc

45.0cc

N/R 82 GPM

1-1/2"

MIL-C-51234

-

-

12

80.0cc

80.0cc

N/R 120 GPM

2"

MIL-C-51234

-

-

12

150.0cc 150.0cc

N/R 185 GPM

Technical Specifications:

Note: Minimum burst pressure ratings were established under laboratory conditions using a Static Burst Unit (SBU).

For high impulse applications and to meet Det Norske Veritas (DNV) compliance, the operating pressure must be

divided by two (2) to ensure a 4:1 safety factor during system operation.

Body

Size

V-Series Snap-Tite H/IH Interchange (Unvalved Connected)

Steel Coupler/Plug

Brass Coupler/Plug

316 SS Coupler/Plug

Maximum Working

Burst

Maximum Working

Burst

Maximum Working

Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

1/4"

11,000 760 29,500 2,000 4,000 275 14,200 980 10,000 670 29,200 2,000

3/8"

11,000 760 29,900 2,000 4,000 275 14,500 1,000 8,000 550 27,900 1,900

1/2"

11,000 760 29,300 2,000 4,000 275 14,500 1,000 8,000 550 24,600 1,700

3/4"

9,000 620 19,300 1,300 3,500 250 11,100 750 7,000 480 22,600 1,500

1"

6,000 400 15,900 1,100 3,000 200 8,200 560 4,000 275 15,500 1,000

1-1/4"

5,000 345 10,000 700 1,000 70 4,000 275 3,000 200 10,000 700

1-1/2"

5,000 345 10,000 700 1,000 70 4,000 275 3,000 200 10,000 700

2"

4,000 275 8,000 550

750

50 2,800 190 1,000 70 6,000 400

Body

Size

V-Series Snap-Tite H/IH Interchange (Valved Connected)

Steel Coupler/Plug

Brass Coupler/Plug

316 Stainless Coupler/Plug

Maximum Working

Burst

Maximum Working

Burst

Maximum Working

Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

1/4"

6,500 450 12,700 876 2,250 150 5,000 345 5,000 345 10,000 700

3/8"

4,500 310 10,500 700 2,250 150 5,300 350 4,000 275 8,000 550

1/2"

4,000 275 9,600 650 2,000 130 5,700 390 3,750 260 7,500 500

3/4"

3,500 240 9,100 600 2,000 130 5,300 350 2,000 130 7,500 500

1"

2,000 130 9,500 650 1,750 120 5,000 345 2,000 130 5,000 345

1-1/4"

1,750 120 5,000 345

350

24 1,000 70 1,500 100 3,000 200

1-1/2"

1,500 100 5,000 345

350

24 1,200 80 1,500 100 3,000 200

2"

1,500 100 4,000 275

400

28 1,000 70

500

34 1,000 70

Rated Pressure Chart:
