163

DQC116

877.963.4966 •

dixonvalve.com

CM-Series Hydraulic Couplings

Body

Size

CM-Series Coupler Rigid Dust Plug

Part Detail

List

Price

Weight

Lb

Package Qty

Part Number

Lanyard

Body

Bag

Box

1/4"

2CMPC-B

N/A

brass

$4.49

0.09

10

100

3/8"

3CMPC-B

N/A

brass

4.49

0.12

10

50

1/2"

4CMPC-B

N/A

brass

9.96

0.15

5

30

Body

Size

CM-Series Industrial Mold Interchange Coupler Seal Kits

Part Detail

List

Price

Seal Kit Contents

Package Qty

Part Number Coupler Style Seal Material

Bag Box

1/4"

2CM-SKIT

all

Silicone

$1.76

Body Seal

25 200

3/8"

3CM-SKIT

all

Silicone

2.01

Body Seal

25 200

1/2"

4CM-SKIT

all

Silicone

3.38

Body Seal

25 200

Counterbored mold ports will protect the male threaded nipple, allowing the nipple to be mounted below the surface, simplifying

storing and handling of molds. Dixon™ male threaded plugs are constructed of corrosion resistant brass to maximize longevity

in moist environments.

Body

Size

Part Detail

Dimension

A

Dimension

B

Part Number

Threads

1/4"

CM2M1-B

1/8" - 27 NPTF

17.5 mm (0.69")

17.5 mm (0.69")

1/4"

CM2M2-B

1/4" - 18 NPTF

21.3 mm (0.84")

23.9 mm (0.94")

1/4"

CM2M3-B

3/8" - 18 NPTF

25.4 mm (1.00")

24.6 mm (0.97")

3/8"

CM3M2-B

1/4" - 18 NPTF

17.5 mm (0.69")

23.9 mm (0.94")

3/8"

CM3M3-B

3/8" - 18 NPTF

21.3 mm (0.84")

28.7 mm (1.13")

3/8"

CM3M4-B

1/2" - 14 NPTF

25.4 mm (1.00")

31.8 mm (1.25")

1/2"

CM4M4-B

1/2" - 14 NPTF

31.8 mm (1.25")

38.1 mm (1.50")

1/2"

CM4M6-B

3/4" - 14 NPTF

38.1 mm (1.50")

39.6 mm (1.56")

A

B
