REMAGRIP
Property
CK-X
200
WHITE
OIL-
FOOD/CN
100
HD/CN
100 /CN 70/CN-
SL
70/CN
10 x 8
70/CN
8 x 6
65/CN 60/CN 50
ORANGE
/CN
Dimensions [mm]
diamond diagonal, axial direction (B)
20
-
-
-
86
86
86
86
35
35
diamond diagonal, radial direction (L)
20
-
-
-
50
50
50
50
18
18
Groove width (S)
17
8
-
-
10
10
8
6
6
6
Groove depth (t)
8
4
-
-
8
8
6
3
3
3
Thickness of lagging (d) [mm]
High-tension steelcord belts
15
-
-
-
15 - 18 15 - 20 15 - 20
-
-
-
Medium-tension steelcord belts
15
-
-
-
12 - 15 15 12 - 15 12
-
-
High-tension fabric belts
15
-
-
-
10 - 15 15 10 - 12 10 - 12 12 - 15 12
Medium-tension fabric belts
15
-
18
-
-
-
-
8 - 10 8 - 12
10
Low-tension fabric belts
15
8
-
12
-
-
-
8
8
8
Pulley diameter up to 500
15
8
-
12
-
-
-
8
8
8
Pulley diameter 500 - 800
15
8
-
12
10
-
-
10
10
10
Pulley diameter 800 - 1 200
15
-
18
12
12
12
12
12
12
12
Pulley diameter above 1 200
15
-
18
12 15 - 18 15 - 20 15 - 20 12
15
12
Technical data
APPLICATION CHART
AND COEFFICIENTS OF FRICTION
Coefficients of friction
Operating conditions
Steel
REMAGRIP Rubber lagging
REMAGRIP C Ceramic lagging
Dry
0.35 to 0.40
0.40 to 0.45
0.75 to 0.85
Wet
0.10 to 0.15
0.33 to 0.38
0.50 to 0.80
Wet and muddy
0.05 to 0.10
0.22 to 0.30
0.45 to 0.55
Coefficient of friction according to the DIN 22101 standard. Friction body: Belt cover in standard quality.
REMAGRIP Pulley Lagging Application Chart:
Coefficients of friction (Pulley - Belt):
Industrie
