• phone: 1-630-971-0150 141
U.S. Patent No. D482,508S
ConShear™ is a trademark of Flexible Steel Lacing Company.
ASGCO® and Skalper® are registered trademarks of ASGCO Mfg, Inc., Allentown, PA.
Additional blade sizes are available upon request. Call for pricing.
NOTE: Blade coverage is the same as the belt width.
Blade design is identical to Argonics replacement blade,
except for length. Can be interchanged.
*Also interchangeable with ASGCO ® Skalper® III Blades.
Lead time: 1 working day
ASGCO® Skalper® IV
9/16"
6-5/8"
ASGCO Skalper IV Blade Design ConShear Blade Design
9/16"
7-1/4"
Lead time: 1 working day
Replacement Blade Pin
Specifications
Usable Blade Volume Comparison
Ordering Information
Part Number
Cross-Reference Guide
Cross-Reference for Replacement
of ASGCO® Skalper® III and IV Blades*
BLADE TYPE
BLADE
LENGTH
Usable BLADE
AREA (cross-
section)
Usable
BLADE VOLUME
ASGCO ® Skalper® IV 28" 3.29 in2 92.1 in3
ConShear ™ 28" 5.50 in2 154.0 in3
SLOT
WIDTH
POLE PLATE
THICKNESS
CONSHEAR
BLADE HEIGHT
SKALPER
BLADE HEIGHT
9/16" 1/2" 7-1/4" 6-5/8"
P R O D U C T H A N D B O O K
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
RB38BP 79481 0.2
BELT
WIDTH
ACTUAL
BLADE
LENGTH
ASGCO®
PART NUMBER
ORDERING
NUMBER
CONSHEAR ™
ITEM CODE
WT.
LBS.
18" 18" ASG-SK4-18A RBAS4-18 76032 8.3
24" 24" ASG-SK4-24A RBAS4-24 76033 11.0
30" 30" ASG-SK4-30A RBAS4-30 76034 13.8
36" 36" ASG-SK4-36A RBAS4-36 76035 16.6
42" 42" ASG-SK4-42A RBAS4-42 76036 19.3
48" 48" ASG-SK4-48A RBAS4-48 76037 22.1
54" 54" ASG-SK4-54A RBAS4-54 76038 24.8
60" 60" ASG-SK4-60A RBAS4-60 76039 27.6
72" 72" ASG-SK4-72A RBAS4-72 76040 33.1
ConShear-LS for ASGCO Mini-Skalper Blades
BELT
WIDTH
BLADE
WIDTH ASGCO
PART NUMBER
ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm in. mm
18 450 12 400 ASG-SBBM-12A RBAMS-12 77376 2.1
24 600 18 550 ASG-SBBM-18A RBAMS-18 77377 3.3
30 750 24 700 ASG-SBBM-24A RBAMS-24 77378 4.6
36 900 30 850 ASG-SBBM-30A RBAMS-30 77379 5.8
42 1050 36 1000 ASG-SBBM-36A RBAMS-36 77380 7.1
48 1200 42 1150 ASG-SBBM-42A RBAMS-42 77381 8.3
Additional sizes are available upon request. Call for pricing.
