U.S. Patent No. D482,508S
ConShear
™
is a trademark of Flexible Steel Lacing Company.
Saber
®
is a registered trademark of Arch Environmental Equipment Inc., Paducah, KY.
Arch/Gordon Saber
®
Channel Mount
Additional blade sizes are available upon request. Call for pricing.
NOTE: Blade coverage is 2 inches less than belt width.
Arch/Gordon Saber Channel Mount
Blade Design
ConShear Blade Design
1-7/16"
5-3/4"
1"
1-7/16"
1"
7-1/4"
Replacement Blade Pin
Specifications
Usable Blade Volume Comparison
Ordering Information
Lead time: 1 working day
Part Number
Cross-Reference Guide
Cross-Reference for Replacement
of Arch/Gordon Saber (SCM)
Channel Mount Blades Blades
BLADE TYPE
BLADE
LENGTH
Usable
BLADE AREA
(cross-section)
Usable
BLADE VOLUME
Arch/Gordon Saber
®
Channel Mount
28"
3.06 in
2
85.7 in
3
ConShear
™
28"
5.50 in
2
154.0 in
3
BASE
WIDTH
CONSHEAR
BLADE HEIGHT
CHANNEL MOUNT
BLADE HEIGHT
1-7/16"
7-1/4"
5-3/4"
P R O D U C T H A N D B O O K
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
EZP1BP
75642
0.1
BELT
WIDTH
ACTUAL
BLADE
LENGTH
ARCH/GORDON
PART NUMBER
ARCH/GORDON
OLD PART
NUMBER
ORDERING
NUMBER
CONSHEAR
™
ITEM CODE
WT.
LBS.
18"
16"
MRBCM00018
SCM-016-18 RBAGSCM-16
76572
7.3
24"
22"
MRBCM00024
SCM-016-24 RBAGSCM-22
76573
10.1
30"
28"
MRBCM00030
SCM-016-30 RBAGSCM-28
76574
12.8
36"
34"
MRBCM00036
SCM-016-36 RBAGSCM-34
76575
15.5
42"
40"
MRBCM00042
SCM-016-42 RBAGSCM-40
76576
18.3
48"
46"
MRBCM00048
SCM-016-48 RBAGSCM-46
76577
21.0
54"
52"
MRBCM00054
SCM-016-54 RBAGSCM-52
76578
23.8
60"
58"
MRBCM00060
SCM-016-60 RBAGSCM-58
76579
26.5
72"
70"
MRBCM00072
SCM-016-72 RBAGSCM-70
76581
32.0
