I-Type™ Replacement Parts
*Hardware included.
Pole Diameter - 2-3/8" (60mm)
Lead time: 1 working day
1
6
6a
3
5
4
2
7
8
5a
Product Ordering
Information
I-Type™
Legacy Belt Cleaner Parts
New Style Clamp Block
(Left Pole
Clamp Kits)
(Right Pole
Clamp Kits)
(Old-Style Clamp
Blocks no longer
available)
P R O D U C T H A N D B O O K
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
18" (450mm) Pole EZS2P18 75652 25.0
24" (600mm) Pole EZS2P24 75653 28.0
30" (750mm) Pole EZS2P30 75654 30.0
36" (900mm) Pole EZS2P36 75655 34.0
42" (1050mm) Pole EZS2P42 75656 36.0
48" (1200mm) Pole EZS2P48 75657 39.0
54" (1350mm) Pole EZS2P54 75658 42.0
60" (1500mm) Pole EZS2P60 75659 77.0
72" (1800mm) Pole EZS2P72 75660 89.0
2 I Standard Cushion* ISC 74534 2.1
3 I C-Tip* (for mechanically splicedand vulcanized belts) ICT6 74535 0.7
4 Adjusting Bracket Kit(1 Right and 1 Left) PAB 75513 1.5
5 Pole Clamp Kit LEFT* (1 ea.) (incl. item 7)(for sizes 18"-54" (450-1350mm) CCKL 79224 6.8
5a HD Pole Clamp Kit LEFT* (1 ea.) (incl. item 7a)for sizes 60"-72" (1500-1800mm) CCKHDL 79225 8.7
6 Pole Clamp Kit RIGHT* (1 ea.) (incl. item 7)for sizes 18"-54" (450-1350mm) CCKR 79228 6.8
6a HD Pole Clamp Kit RIGHT* (1 ea.) (incl. item 7a)for sizes 60"-72" (1500-1800mm) CCKHDR 79229 8.7
7 Cradle Clamp Top Strap (1 ea.)for use on L or R Pole Clamp Kit CCKTS 79232 1.1
7a HD Cradle Clamp Top Strap (1 ea.)for use on L or R HD Pole Clamp Kit CCKHDTS 79233 1.7
8 Mounting Bracket Kit(1 Right and 1 Left) EZS2MBK 75666 13.0
–
Cradle Clamp Mounting Kit*
for sizes 18"-54" (450-1350mm)
(incl. 1 ea. Items 5, 6, & 8, 2 ea. Items 4 & 7)
CCMK 78919 33.0
–
HD Cradle Clamp Mounting Kit*
for sizes 60"-72" (1500-1800mm)
(incl. 1 ea. Items 5a, 6a, & 8, 2 ea. Items 4 & 7a)
CCMKHD 78920 36.7
