MAXZONE
tm
Skirting System
Standard Clamp
Designed to ensure skirt delivers consistent
seal
Economical solution for load point spillage
Safe service access, long service life
Bolt option comes in powder-coated,
galvanized or stainless steel
Swivel handle option comes in galvanized
only
Available in 4’ and 6’modular sections
Quick Release Clamp
Simple maintenance without the use of tools
Skirting adjustments and replacements are quick
and easy
Comes in standard 1m and 4’modules
Easy 4 step installation process
1.
Weld channel strut to skirt board
2. Slide clamps through channel strut
3. Slide on aluminum angle brackets
4. Twist clamps to tighten, then pull
down to lock
Seals
Clamps
Superior seal with
a great price
Polyurethane
provides lower
friction than rubber
and lasts twice as
long
Simple seal to
get the job done
Exceptional sealing
when belt edge
distance is minimal
thane seal outlasts
other products
such as steel,
UHMW and rubber
Classic Seal
B-Seal
B-Plus Seal
Classic Plus Seal Classic Poly Seal
The solid polyure-
