MAXZONE
tm
Warrior Impact & Roller Beds
Warrior Impact Bed
The Warrior Impact Bed stabilizes and supports the conveyor belt during
loading, defending it from damage. The stiff, rigid frame and soft rubber bars
of the Warrior cushion the belt and absorb impact. The end result is longer belt
life, eliminated spillage and decreased O&M costs.
Rubber bars absorb impact to protect conveyor belt
Durable frame of steel supports impact on the bars
“Fine-Tune”wing adjustment for optimum sealing
Wings and center sections slide in and out for easy access
Impact bar change outs are quick, keeping downtime to a minimum
Meets CEMA design standards: No.502-1998 & 575-2000
Warrior Roll & Guide Support Bed
The Warrior Roll & Guide Support Bed creates a seamless seal helping to
eliminate dust and spillage in the loadzone.The effective design of the Roll
& Guide Bed utilizes low friction, UHMW top cover slider bars on the wing
sections and rollers in the center. As a result, the conveyor drag is minimized
while the belt is fully supported at the edges- right where it is needed. The
adjustable wing sections ensure a flat level surface for the conveyor belt
and the loadzone giving the sealing system the ability to achieve optimal
performance.
Benefits
Easy to install and maintain
Increases skirtboard life
Removes gaps between skirtboard and seal
Eliminates crimping of interior skirt liners
Features
Adjusts to fit trough angles
Low friction bars
Center standard or impact rollers
