P-Series Pneumatic Couplings

Interchange Data:

Thor Finger-Lock Interchange

Interchanges with Thor PHC-Series, National Series 'A',

and Dual-Lock.

Materials:

Machined components are manufactured using solid steel,

brass, or 303 stainless steel bar stock.

Phosphor Bronze retaining ring and spring maximize

corrosion resistance and extend service life.

Steel componentry is plated using ROHS Compliant

Trivalent Chrome.

Steel couplings have a Zinc Cast sleeve

Nitrile (Buna-N) seals are standard, temperature range

-40°F

to

+250°F

(

-40°C

to

+121°C

).

Seal Components:

Body

Size

P-Series Thor Interchange (Connected)

Steel Coupler/Plug

Brass Coupler/Plug

303 Stainless Steel Coupler/Plug

Max. Working

Burst

Max. Working

Burst

Max. Working

Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

1/2"

300

20 2,600 180

300

20 3,500 240

300

20 4,500 310

Rated Pressure Chart:

Technical Specifications:

Body

Size

Interchange Standards

Functional Parameters

U.S.

Military

U.S.

Government

International

Standards

ANSI/NFPA

Standards

Locking

Mechanism

Air

Inclusion

Fluid

Loss

Vacuum

Rating

Flow

ΔP = 15 PSI

1/2"

-

-

-

-

Latch

Fingers

N/A

N/A

N/R 255 CFM

Body

Size

Seals

Sleeve Options

Staked Ferrule Option

FKM

Flanged

Lock Clip

1/2" Barb

3/4" Barb 3/4" Stainless Barb

Prefix Add $ Suffix Add $ Part

Number List $ Suffix Add $ Suffix Add $ Suffix Add $

1/2"

F-

$7.20

-FS

$3.65

4P-CLIP

$1.76

-WF43

$8.15

-WF63

$8.15

-WFS63

$10.80

List Price Option Adders:

P Series Coupler with

-FS Flanged Sleeve Option
