Table 5 Belt Deflection Force

Belt Deflection (force pounds)

Uncogged HY-T®

Belts and Uncogged

HY-T® Torque Team®

Cogged Torque-Flex®

and Machined Edge

Torque Team® Belts

Cross

Section

Smallest

Sheave

Diameter

Range

RPM Range

New

Belt

Used

Belt

New

Belt

Used

Belt

A, AX

3.0-3.6

1000-2500 5.5

3.7

6.1

4.1

2501-4000 4.2

2.8

5.0

3.4

3.8-4.8

1000-2500 6.8

4.5

7.4

5.0

2501-4000 5.7

3.8

6.4

4.3

5.0-7.0

1000-2500 8.0

5.4

9.4

5.7

2501-4000 7.0

4.7

7.6

5.1

B, BX

3.4-4.2

860-2500

7.2

4.9

2501-4000

6.2

4.2

4.4-5.6

860-2500 7.9

5.3

10.5

7.1

2501-4000 6.7

4.5

9.1

6.2

5.8-8.6

860-2500 9.4

6.3

12.6

8.5

2501-4000 8.2

5.5

10.9

7.3

C, CX

7.0-9.0

500-1740 17.0

11.5

21.8

14.7

1741-3000 13.8

9.4

17.5

11.9

9.5-16.0

500-1740 21.0

14.1

23.5

15.9

1741-3000 18.5

12.5

21.6

14.6

D

12.0-16.0

200-850 37.0

24.9

851-1500 31.3

21.2

18.0-20.0

200-850 45.2

30.4

851-1500 38.0

25.6

V-Belts

Installation Guide

Mark the center of the span. At the center mark, use

a tension tester and apply a force perpendicular to

the span large enough to deflect the belt 1/64 inch

for every inch of span length (example: a 100 inch

span requires a deflection of 100/64 inch or

1_⁄{| inches).

Compare the actual deflection force with the values

in Tables 5, 6 and 7 (at right and page 14). A force

below the target value indicates under-tension.

A force above the target indicates over-tension.

Force

Span Length

Deflection 1/64 in. per in. of span

Measuring the Span Length

V-Belts

Installation Guide
