Modular belt conveyor
Belt diverter
Pop-up sorter
Telescopic conveyor
Crossbelt sorter
Telescopic conveyor
Line belt
Remark:
The drawings show schematic examples of selected applications/processes. The drawings don’t lay claim to
completeness. The belt recommendations (use/application/layout) can only be considered as a general hint. Due to
the complexity of the various processes and technical requirements and the decisive external influences (e.g. nature or
property of transported goods, process speed, steps of treatment/handling, environment or process temperature,
humidity, chemicals, additives, ingredients, recipes, etc.) there is a large variety of solutions possible.
Modular belt radius conveyor
Incline/decline conveyor
Pop-up sorter with round belts
