Deflection Forces for Belt Tensioning (lb.)
Noncogged
Single, Torque
Team®* &
Torque Team
Plus®* Belts
Cogged Single
& Torque Team®*
Smallest Sheave
Diameter Range
RPM
Range
New
Belt
Used
Belt
New
Belt
Used
Belt
A, AX Cross Section
3.0-3.6
1000-2500 5.5 3.7 6.1 4.1
2501-4000 4.2 2.8 5.0 3.4
3.8-4.8
1000-2500 6.8 4.5 7.4 5.0
2501-4000 5.7 3.8 6.4 4.3
5.0-7.0
1000-2500 8.0 5.4 9.4 5.7
2501-4000 7.0 4.7 7.6 5.1
B, BX Cross Section
3.4-4.2
860-2500 N/A N/A 7.2 4.9
2501-4000 N/A N/A 6.2 4.2
4.4-5.6
860-2500 7.9 5.3 10.5 7.1
2501-4000 6.7 4.5 9.1 6.2
5.8-8.6
860-2500 9.4 6.3 12.6 8.5
2501-4000 8.2 5.5 10.9 7.3
C, CX Cross Section
7.0-9.0
500-1740 17.0 11.5 21.8 14.7
1741-3000 13.8 9.4 17.5 11.9
9.5-16.0
500-1740 21.0 14.1 23.5 15.9
1741-3000 18.5 12.5 21.6 14.6
D Cross Section
12.0-16.0
200-850
37.0 24.9 N/A N/A
851-1500 31.3 21.2 N/A N/A
18.0-20.0
200-850
45.2 30.4 N/A N/A
851-1500 38.0 25.6 N/A N/A
3V, 3VX, XPZ Cross Section
2.2-2.4
1000-2500 N/A N/A 4.9 3.3
2501-4000 N/A N/A 4.3 2.9
2.65-3.65
1000-2500 5.1 3.6 6.2 4.2
2501-4000 4.4 3.0 5.6 3.8
4.12-6.90
1000-2500 7.3 4.9 7.9 5.3
2501-4000 6.6 4.4 7.3 4.9
SPA, XPA Cross Section
3.0-4.1
1000-2500 N/A N/A 9.0 6.1
2501-4000 N/A N/A 7.9 5.2
4.2-5.7
1000-2500 10.1 6.7 12.4 8.3
2501-4000 8.3 5.6 11.2 7.4
5.7-10.1
1000-2500 14.6 9.7 15.3 10.1
2501-4000 12.6 8.5 13.7 9.2
V-Belts
Tensioning Tables
Deflection Forces for Belt Tensioning (lb.)
Noncogged
Single, Torque
Team®* &
Torque Team
Plus®* Belts
Cogged Single
& Torque Team®*
Smallest Sheave
Diameter Range
RPM
Range
New
Belt
Used
Belt
New
Belt
Used
Belt
5V, 5VX, SPB, XPB Cross Section
4.4-6.7
500-1749 N/A N/A 15.2 10.2
1750-3000 N/A N/A 13.2 8.8
3001-4000 N/A N/A 8.5 5.6
7.1-10.9
500-1740 18.9 12.7 22.1 14.8
1741-3000 16.7 11.2 20.1 13.7
11.8-16.0
500-1740 23.4 15.5 25.5 17.1
1741-3000 21.8 14.6 25.0 16.8
SPC, XPC Cross Section
8.3-14.3
500-1000 31.0 20.7 33.3 22.3
1000-1750 28.6 19.1 32.4 21.6
14.4-20.1
500-1000 39.3 26.3 41.8 27.9
1000-1750 37.5 25.2 45.6 30.3
8V, 8VX Cross Section
12.5-17.0
200-850
49.3 33.0 N/A N/A
851-1500 39.9 26.8 N/A N/A
18.0-22.4
200-850
59.2 39.6 N/A N/A
851-1500 52.7 35.3 N/A N/A
5VF Cross Section
7.1-10.9
200-700
30.9 21.1 N/A N/A
701-1250 26.3 18.0 N/A N/A
1251-1900 23.4 16.7 N/A N/A
1901-3000 23.0 15.8 N/A N/A
11.8-16.0
200-700
39.5 26.8 N/A N/A
701-1250 34.7 23.5 N/A N/A
1251-2100 33.3 22.7 N/A N/A
8VF Cross Section
12.0-20.0
200-500
65.8 44.7 N/A N/A
501-850
56.6 38.5 N/A N/A
851-1150
51.6 35.2 N/A N/A
1151-1650 49.0 33.5 N/A N/A
21.2-25.0
200-500
97.6 65.9 N/A N/A
501-850
90.6 61.2 N/A N/A
851-1200 84.3 57.0 N/A N/A
*Multiply table values by the number of Torque Team® ribs to achieve recommended
tensioning value.
1. The table deflection forces and strand tensions are typically at maximum values to cover
the broad range of loads, rpm and pulley combinations for all possible drives.
2. For drives where hub loads are critical, high speed drives or other drives with special
circumstances, the belt deflection force and strand installation tension should be
calculated by using formulas found in existing engineering manuals or use the
MaximizerPro™ Drive Selection Analysis Program.
3. Consult the TensionRite® Belt Frequency Meter manual for detailed information on using
the frequency based tension gauge.
4. Continental ContiTech offers three different levels of tension gauges to aid you in
properly tensioning your power transmission belts. See your Sales Representative or
Distributor for more information on tensioning gauges.
Troubleshooting
V-Belts Tensioning Tables
