MAXCLEAN
Secondary Belt Cleaners
BES1
BES2
BXS1
BXS2
BXS3
Unparalleled Blade Holder Keeps the Center of the Blade on the Belt
Blade arcs into the center as it wears to maintain continuous blade-to-belt contact
Blade pivots and bends around central pivot, following and conforming to uneven worn belts
One-Piece Rubber Blade with Tungsten Carbide Tips
Blade flaps ensure carryback slides away from the blade and doesn’t build up on the blade or
frame
Also available in solid rubber for effective water removal
Rosta joint tensioner to absorb sever impacts
Low Profile Cleaner Design
Works great in confined space chutes
Overall height is just 5”
Special Blade Cartridge Design
Secondary cleaner for one direction or reversing belts
Allows blade to move down and over to reversing position
Tungsten carbide blades are mounted in SBR rubber cushions for independent movement on
the belt
Three inch wide cushions and blades
Cushions are individually actuated; allows each blade to self-adjust to the belt as it wears
Safe to Service
All blade tensioning can be done safely from the sides of the conveyor
Pull-out blade cartridge design ensures worn blades can be easily removed
Patented Floating Cushions on a Fluid-Filled Tube
Segmented cushions/blades automatically adjust to the contour of the belt for uniform
cleaning
Pressure equilibrating center chamber moves blades up and down during operation to
provide optimum blade/belt contact
Can be Mounted Directly Under Head Pulley
Fits in confined space and drops carryback directly into the chute
Stainless Steel Construction
Holds up to high acidity applications
Long service life
UHMW Cushion/Blade Shields
Sheds carryback quickly away from the cleaner
Protects cushions from material buildup
4” Blade with Built-In Torsion Arm Segments
Arm segment allows blade movement to clean even worn belts
4”width allows blades to independently flow on contours of the belt
Built-in shields keep blades free of material buildup
Exclusive Dual Torsion System
Segments in each blade keep blade pressure consistent and allow blades to respond/react
individually
Tensioners provide extra shock absorption when needed
Unique blade designs for one direction and reversing belts
High Efficiency Secondary Cleaner
Compact enough to fit in most chute applications
Sits close enough to the pulley to ensure the material fines are directed back into the regular
material flow
Superior wear resistance
Equipped with stainless or carbon steel individual blades
Durable tungsten carbide inserts
Dual tensioning for better pressure distribution
