Valves
P
593 DPL413 877.963.4966 • dixonvalve.com
Electrically Actuated 3-Way Brass Ball Valves - 'T / L' Port
A wide variety of options are available: modulating, extra switches, transmitters, potentiometer, etc.
Contact Dixon Sanitary at 800.789.1718 or visit bradfordfittings.com for details.
Dimensions are approximate. Engineering dimensions are available upon request.
Specifications are subject to change without notice.
¼" - 1¼" 1½" - 3"
C D
ØB
A
D C
ØB
A
* T = t-style
* L = l-style
Features:
3-Way Brass Ball Valve
•reduced port
•blow-out proof stem
•chrome-plated brass ball
•PTFE seats with O-ring backing for low operating
torque
•PTFE seats and double O-ring stem packing
•ISO 5211 mounting pad
•100% tested
•pressure rating:400 PSI WOG100 PSI WSP
•maximum temperature:344ºF
Electric Actuator
•lightweight powder coated aluminum alloy housing
•NEMA 4/4X waterproof and dustproof
•extended duty cycle induction motor
•high alloy steel gear train
•H-insulation class
•visual position indication
•space heater is standard
•manual override standard: ½" - 1½"
•working temperature:-41°F to 140°F
•ISO 9001, CS, CE and CSA-C US Certified
•RoHS compliant
Caution !
Even though there are torque safety factors built into our automated ball valve packages, actual service conditions
must also be considered when selecting the proper product for the appropriate application.
For example: Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other
viscous fluids can have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators
may be required. Please consult the factory when dealing with these types of applications.
Size A B C D Override Brass Part #
110VAC
Voltage
-EA
24VDC
Voltage
-EG
12VDC
Voltage
-ET
220VAC
Voltage
-EK
24VAC
Voltage
-ES
1/4" 8.76 6.06 2.64 1.32 standard BV3BV*R-0251 $955.60 $955.60 $955.60 $955.60 $955.60
3/8" 8.76 6.06 2.64 1.32 standard BV3BV*R-0381 955.60 955.60 955.60 955.60 955.60
1/2" 8.76 6.06 2.87 1.44 standard BV3BV*R-0501 955.60 955.60 955.60 955.60 955.60
3/4" 8.85 6.06 3.19 1.60 standard BV3BV*R-0751 979.15 979.15 979.15 979.15 979.15
1" 9.19 6.06 3.74 1.87 standard BV3BV*R-1001 1012.70 1012.70 1012.70 1012.70 1012.70
1¼" 9.41 6.06 4.39 2.20 standard BV3BV*R-1251 1117.25 1117.25 1117.25 1117.25 1117.25
1½" 9.90 6.06 4.86 2.43 N/A BV3BV*R-1501 1381.05 1381.05 1381.05 1381.05 1381.05
2" 10.89 4.25 5.73 2.87 N/A BV3BV*R-2001 1988.95 1988.95 1988.95 1988.95 1988.95
2½" 11.34 4.25 6.93 3.47 N/A BV3BV*R-2501 2911.35 2911.35 2911.35 2911.35 2911.35
3" 11.34 4.25 7.08 3.54 N/A BV3BV*R-3001 2780.25 2780.25 2780.25 2780.25 2780.25
See page 595 for flow path options.
A flow path needs to be selected at time of
order. If no flow path is selected, the option
number labeled as default will be shipped.
Customer verification is critical. If flow path
needs to be changed after being shipped,
labor and shipping charges will apply.
For spring return actuators: must not fail
position.
