Valves

DPL413

P

877.963.4966 • dixonvalve.com

594

Pneumatically Actuated 3-Way Brass Ball Valves - 'T / L' Port

Spring Return (normally closed)

Double Acting

A wide variety of switches, solenoids, positioners, etc., are available.

Contact Dixon Sanitary at 800.789.1718 or visit bradfordfittings.com for details.

E

D

C

B

A

E

C

D

A

B

Features:

3-Way Brass Ball Valve

•

reduced port

•

blow-out proof stem

•

chrome-plated brass ball

•

PTFE seats with O-ring backing for low operating torque

•

PTFE seats and double O-ring stem packing

•

ISO 5211 mounting pad

•

100% tested

•

pressure rating:

400 PSI

WOG

100 PSI

WSP

•

maximum temperature:

344ºF

Rack and Pinion Actuator

•

hard anodized aluminum body

•

nickel plated anti-blowout pinion

•

Buna-N O-rings

•

NAMUR mounting

•

bi-directional stops for ±5º travel adjustment

•

80 PSI plant air required

•

visual position indication

•

maximum operating pressure:

120 PSI

•

operating temperature range:

-40ºF

to

200ºF

•

tested to one million cycles

Caution !

Even though there are torque safety factors built into our automated ball valve packages, actual service conditions

must also be considered when selecting the proper product for the appropriate application.

For example:

Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other

viscous fluids can have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators

may be required. Please consult the factory when dealing with these types of applications.

*

T

= t-style

*

L

= l-style

All dimensions are given in inches, unless noted. Dimensions

are approximate. Engineering dimensions are available upon

request. Specifications are subject to change without notice.

Size

A

B

C

D E

Brass

Part #

Price/E

1/4" 4.72 2.80 2.64 5.49

1.32

BV3BV*R-0251BBC

$626.30

3/8" 4.72 2.80 2.64 5.49

1.32

BV3BV*R-0381BBC

626.30

1/2" 4.72 2.80 2.87 5.49 1.44

BV3BV*R-0501BBC

626.30

3/4" 4.81 2.80

3.19

5.49 1.60

BV3BV*R-0751BBC

663.15

1"

6.28 3.74 3.74 7.45 1.87

BV3BV*R-1001BBC

774.35

1¼"

6.50 3.74 4.39 7.45

2.20

BV3BV*R-1251BBC

900.85

1½"

6.99 3.74 4.86 7.45 2.43

BV3BV*R-1501BBC

1189.35

2"

8.45 4.69 5.73

9.10

2.87

BV3BV*R-2001BBC

1669.00

2½"

8.90 4.69 6.93

9.10

3.47

BV3BV*R-2501BBC

2574.20

3"

8.90 4.69 7.08

9.10

3.54

BV3BV*R-3001BBC

2511.55

Dimensions are approximate. Engineering dimensions are available upon

request. Specifications are subject to change without notice.

Size

A

B

C

D E

Brass

Part #

Price/E

1/4" 3.76 1.77 2.64 4.33

1.32

BV3BV*R-0251BCC

$479.20

3/8" 3.76 1.77 2.64 4.33

1.32

BV3BV*R-0381BCC

479.20

1/2" 3.76 1.77 2.87 4.33 1.44

BV3BV*R-0501BCC

489.00

3/4" 3.85 1.77

3.19

4.33 1.60

BV3BV*R-0751BCC

528.50

1" 5.53 3.20

3.74

5.32

1.87

BV3BV*R-1001BCC

637.05

1¼"

5.75

3.20

4.39

5.32 2.20

BV3BV*R-1251BCC

768.85

1½"

6.24

3.20

4.86

5.32

2.43

BV3BV*R-1501BCC

1016.15

2"

7.55 3.74 5.73

5.51

2.87

BV3BV*R-2001BCC

1434.15

2½"

8.00 3.74 6.93

5.51

3.47

BV3BV*R-2501BCC

2295.90

3"

8.00 3.74 7.08

5.51

3.54

BV3BV*R-3001BCC

2241.95

See page 595 for flow path options.

A flow path needs to be selected at time

of order. If no flow path is selected, the

option number labeled as default will be

shipped.

Customer verification is critical. If flow

path needs to be changed after being

shipped, labor and shipping charges will

apply.

For spring return actuators: must not fail

position.
