Electrically Actuated 3-Way Stainless Ball Valves - 'T / L' Port
Dimensions are approximate. Engineering dimensions are available upon request.
Specifications are subject to change without notice.
A wide variety of options are available: modulating, extra switches, transmitters, potentiometer, etc.
Contact Dixon Sanitary at 800.789.1718 or visit bradfordfittings.com for details.
See page 595 for flow path options.
A flow path needs to be selected at time of
order. If no flow path is selected, the option
number labeled as default will be shipped.
Customer verification is critical. If flow path
needs to be changed after being shipped,
labor and shipping charges will apply.
For spring return actuators: must not fail
position.
¼" - 1¼" 1½" - 2"
ØB
C D
A
ØB E
A
C
* T = t style
* L = l style
Features:
3-Way Stainless Ball Valve
• full port
•female NPT ends
•blow-out proof stem
•live-loaded stem packing
•ISO 5211 mounting pad
•100% air tested under water at80 PSI
•working pressure: ¼" to 1":1000 PSI;
1¼" to 2":800 PSI
•temperature range:-20°F to 450°F
Electric Actuator
•lightweight powder coated aluminum alloy
housing
•NEMA 4/4X waterproof and dustproof
•extended duty cycle induction motor
•high alloy steel gear train
•H-insulation class
•visual position indication
•space heater is standard
•manual override standard: ½" - 1½"
•working temperature:-41°F to 140°F
•ISO 9001, CS, CE and CSA-C US Certified
•RoHS compliant
Caution !
Even though there are torque safety factors built into our automated ball valve packages, actual service conditions
must also be considered when selecting the proper product for the appropriate application.
For example: Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other
viscous fluids can have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators
may be required. Please consult the factory when dealing with these types of applications.
Size A B C D E Override 316 Stainless Steel
Part #
110VAC
Voltage
-EA
24VDC
Voltage
-EG
12VDC
Voltage
-ET
220VAC
Voltage
-EK
24VAC
Voltage
-ES
1/4" 9.01 6.06 2.83 1.41 N/A standard BV3IG*F-0251 $1184.10 $1184.10 $1184.10 $1184.10 $1291.30
3/8" 9.01 6.06 2.83 1.41 N/A standard BV3IG*F-0381 1184.10 1184.10 1184.10 1184.10 1291.30
1/2" 9.21 6.06 3.26 1.63 N/A standard BV3IG*F-0501 1184.10 1184.10 1184.10 1184.10 1291.30
3/4" 9.21 6.06 3.89 1.94 N/A standard BV3IG*F-0751 1313.05 1313.05 1313.05 1313.05 1420.25
1" 9.74 6.06 4.40 2.20 N/A standard BV3IG*F-1001 1456.30 1456.30 1456.30 1456.30 1563.50
1¼" 10.04 6.06 4.92 2.46 N/A standard BV3IG*F-1251 1715.40 1715.40 1715.40 1715.40 1822.60
1½" 12.92 7.87 5.86 2.93 12.99 handwheel BV3IG*F-1501 2817.10 2817.10 2817.10 2817.10 3080.60
2" 13.67 7.87 6.85 3.42 12.99 handwheel BV3IG*F-2001 3664.70 3664.70 3664.70 3664.70 4392.20
