Electrically Actuated 3-Piece Stainless Ball Valves
Dimensions are approximate.
Engineering dimensions are available upon request. Specifications are subject to change without notice.
Features:
3-Piece Stainless Ball Valve
•15% glass reinforced RTFE seats
•blow-out proof stainless steel stem
•live-loaded stem packing
•ISO 5211 mounting pad
•swing out in-line easy maintenance
•½" - 2" rated to1000 PSI WOG; 3" rated to800 PSI WOG
•temperature range: -40°F to 400°F
Electric Actuator
•lightweight powder coated aluminum alloy housing
•NEMA 4/4X waterproof and dustproof
•extended duty cycle induction motor
•high alloy steel gear train
•H-insulation class
•visual position indication
•space heater is standard
•manual override standard: ½" - 1½"
•working temperature:-41°F to 140°F
•ISO 9001, CS, CE and CSA-C US Certified
•RoHS compliant
A wide variety of options are available: modulating, extra switches, transmitters, potentiometer, etc.
Contact Dixon Sanitary at 800.789.1718 or visit bradfordfittings.com for details.
½" - 1½"
BØ
A
F to F
2"
BØ
A
F to F
3"
BØ
A
F to F
½" - 1¼" 3" 1½" - 2"
Caution !
Even though there are torque safety factors built into our automated ball valve packages, actual service conditions
must also be considered when selecting the proper product for the appropriate application.
For example: Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other
viscous fluids can have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators
may be required. Please consult the factory when dealing with these types of applications.
Size F to F A B Override 316 Stainless Steel
Part #
110VAC
Voltage
-EA
24VDC
Voltage
-EG
12VDC
Voltage
-ET
220VAC
Voltage
-EK
24VAC
Voltage
-ES
½" 2.6 7.8 4.5 standard BV2IG-05011 $1063.05 $919.45 $919.45 $919.45 $1026.65
¾" 3.0 8.0 4.5 standard BV2IG-07511 946.60 946.60 946.60 946.60 1224.65
1" 3.4 8.3 4.5 standard BV2IG-10011 1174.50 987.65 987.65 987.65 1094.85
1¼" 4.0 8.5 4.5 standard BV2IG-12511 1282.80 1045.45 1045.45 1045.45 1152.65
1½" 4.7 9.2 4.5 N/A BV2IG-15011 1413.95 1124.30 1124.30 1124.30 1231.50
2" 5.2 11.4 4.5 N/A BV2IG-20011 1544.55 1594.75 2043.65 1488.00 1488.00
3" 7.2 12.2 6.1 N/A BV2IG-30011 2922.80 3851.50 3398.35 2880.30 3501.90
4" 8.9 16.1 7.1 N/A BV2IG-40011 5160.00 5067.45 5144.80 5067.45 5067.45
