Valves
DPL413
P
877.963.4966 • dixonvalve.com 586
Pneumatically Actuated 2-Piece Stainless Ball Valves
Spring Return (normally closed)
Double Acting
Features:
2-Piece Stainless Ball Valve
•RTFE seats and seals
•blow-out proof stem
•live-loaded stem packing
•ISO 5211 mounting pad
• pressure rating: ¼" - 2"1000 PSI WOG, 2½" - 3"800 PSI WOG
•temperature range: -40°F to 450°F
Rack and Pinion Actuator
•hard anodized aluminum body
•nickel plated anti-blowout pinion
•Buna-N O-rings
•NAMUR mounting
•bi-directional stops for ±5º travel adjustment
•80 PSI plant air required
•visual position indication
•maximum operating pressure:120 PSI
•operating temperature range:-40ºF to 200ºF
•tested to one million cycles
A wide variety of switches, solenoids, positioners, etc., are available.
Contact Dixon Sanitary at 800.789.1718 or visit bradfordfittings.com for details.
C
D B
A
C
D B
A
Caution !
Even though there are torque safety factors built into our automated ball valve packages, actual service conditions
must also be considered when selecting the proper product for the appropriate application.
For example: Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other
viscous fluids can have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators
may be required. Please consult the factory when dealing with these types of applications.
Dimensions are approximate. Engineering dimensions are available upon
request. Specifications are subject to change without notice.
Size A B C D 316 Stainless Steel
Part # Price/E
1/4" 5.21 2.80 2.56 5.49 BV2HG-02511-BBC $519.80
3/8" 5.21 2.80 2.56 5.49 BV2HG-03811-BBC 524.90
1/2" 5.16 2.80 2.95 5.49 BV2HG-05011-BBC 550.40
3/4" 5.26 2.80 3.15 5.49 BV2HG-07511-BBC 555.25
1" 6.64 3.74 3.54 8.09 BV2HG-10011-BBC 602.20
1¼" 6.84 3.74 4.33 8.09 BV2HG-12511-BBC 646.90
1½" 8.14 4.69 4.72 9.84 BV2HG-15011-BBC 834.10
2" 8.69 4.69 5.51 9.84 BV2HG-20011-BBC 1112.85
2½" 9.54 5.53 7.28 13.98 BV2HG-25011-BBC 1519.95
3" 11.39 7.29 8.07 16.61 BV2HG-30011-BBC 3382.75
Dimensions are approximate. Engineering dimensions are available upon
request. Specifications are subject to change without notice.
Size A B C D 316 Stainless Steel
Part # Price/E
1/4" 4.25 1.77 2.56 4.33 BV2HG-02511-BCC $372.45
3/8" 4.25 1.77 2.56 4.33 BV2HG-03811-BCC 355.70
1/2" 4.20 1.77 2.95 4.33 BV2HG-05011-BCC 361.25
3/4" 4.30 1.77 3.15 4.33 BV2HG-07511-BCC 398.95
1" 5.89 3.20 3.54 5.68 BV2HG-10011-BCC 503.90
1¼" 6.09 3.20 4.33 5.68 BV2HG-12511-BCC 548.55
1½" 7.24 3.74 4.72 5.87 BV2HG-15011-BCC 689.20
2" 7.79 3.74 5.51 5.87 BV2HG-20011-BCC 1110.55
2½" 8.75 4.69 7.28 7.20 BV2HG-25011-BCC 1387.70
3" 10.01 5.53 8.07 10.22 BV2HG-30011-BCC 2900.30
