Valves
P
585 DPL413 877.963.4966 • dixonvalve.com
Electrically Actuated 2-Piece Stainless Ball Valves
Dimensions are approximate.
Engineering dimensions are available upon request. Specifications are subject to change without notice.
Features:
2-Piece Stainless Ball Valve
•RTFE seats and seals
•blow-out proof stem
•live-loaded stem packing
•ISO 5211 mounting pad
• pressure rating: ¼" - 2"1000 PSI WOG, 2½" - 3"800 PSI WOG
•temperature range:-40°F to 450°F
Electric Actuator
•lightweight powder coated aluminum alloy housing
•NEMA 4/4X waterproof and dustproof
•extended duty cycle induction motor
•high alloy steel gear train
•H-insulation class
•visual position indication
•space heater is standard
•manual override standard: ½" - 1½"
•working temperature:-41°F to 140°F
•ISO 9001, CS, CE and CSA-C US Certified
•RoHS compliant
Caution !
Even though there are torque safety factors built into our automated ball valve packages, actual service conditions
must also be considered when selecting the proper product for the appropriate application.
For example: Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other viscous fluids can
have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators may be required.
Please consult the factory when dealing with these types of applications.
A wide variety of options are available: modulating, extra switches, transmitters, potentiometer, etc.
Contact Dixon Sanitary at 800.789.1718 or visit bradfordfittings.com for details.
¼" - 1¼" 2½" - 3" 1½" - 2"
* for 110VAC 2½" with manual override use EP
Size A B C D E Override 316 Stainless Steel
Part #
110VAC
Voltage
-EA
24VDC
Voltage
-EG
12VDC
Voltage
-ET
220VAC
Voltage
-EK
24VAC
Voltage
-ES
1/4" 7.79 4.50 2.56 1.40 NA standard BV2HG-02511 $879.70 $879.70 $879.70 $879.70 $879.70
3/8" 7.79 4.50 2.56 1.40 NA standard BV2HG-03811 897.70 897.70 897.70 897.70 897.70
1/2" 7.74 4.50 2.95 1.40 NA standard BV2HG-05011 903.60 903.60 903.60 903.60 903.60
3/4" 7.84 4.50 3.15 1.75 NA standard BV2HG-07511 904.15 904.15 904.15 904.15 904.15
1" 8.09 4.50 3.54 1.75 NA standard BV2HG-10011 954.20 954.20 954.20 954.20 954.20
1¼" 8.29 4.50 4.33 2.58 NA standard BV2HG-12511 998.85 998.85 998.85 998.85 998.85
1½" 8.69 4.50 4.72 2.97 NA N/A BV2HG-15011 1083.35 1083.35 1083.35 1083.35 1083.35
2" 11.13 4.50 5.51 2.73 NA N/A BV2HG-20011 1548.35 1548.35 1548.35 1548.35 1548.35
2½" 13.72 7.08 7.28 4.68 12.83 handwheel BV2HG-25011-EP * 2675.35 -- -- -- --
2½" 10.69 6.06 7.28 4.68 NA N/A BV2HG-25011 2675.35 2675.35 2675.35 2675.35 2675.35
3" 13.72 7.08 8.07 5.44 12.83 handwheel BV2HG-30011 4384.25 4384.25 4384.25 4384.25 4384.25
