Valves
DPL413
P
877.963.4966 • dixonvalve.com
584
316 Stainless Steel 3-Piece Ball Valves
316 Stainless Steel 2-Piece Domestic Ball Valves
Full Port
Features:
•
rated to
1,000 PSI
Cold Working Pressure
•
rated to
150 PSI
saturated steam
•
vacuum service to 29 inches Hg
•
316 stainless body, ball and stem
•
PTFE seals
•
blow-out proof stem
•
vinyl handle cover
•
full port
•
temperature range:
-40°F
to
400°F
Full Port
Size
Port
Type
PSI
@ 65°F
Body
Length
Female NPT
Socket Weld
316 Stainless Steel
316 Stainless Steel
Part #
Price/E
Part #
Price/E
½"
full
1000
2.5"
BV2IG-05011-A
$105.00
BV2IG-05033-A
$105.00
¾"
full
1000
3.1"
BV2IG-07511-A
131.45
BV2IG-07533-A
131.45
1"
full
1000
3.3"
BV2IG-10011-A
171.45
BV2IG-10033-A
171.45
1¼"
full
1000
4.1"
BV2IG-12511-A
227.70
BV2IG-12533-A
227.70
1½"
full
1000
4.4"
BV2IG-15011-A
311.60
BV2IG-15033-A
311.60
2"
full
1000
5.1"
BV2IG-20011-A
443.95
BV2IG-20033-A
443.95
2½"
full
800
6.6"
BV2IG-25011-A
887.55
BV2IG-25033-A
887.55
3"
full
800
7.3"
BV2IG-30011-A
1260.00
BV2IG-30033-A
1260.00
4"
full
600
8.9"
BV2IG-40011-A
2178.85
BV2IG-40033-A
2178.85
Features:
•
FNPT ends or socket weld
•
blow out proof stem
•
live-loaded stem packing
•
swing out design for easy maintenance
•
ISO 5211 mounting pad
•
RTFE seat and seals
•
maximum temperature:
400°F
female NPT x female NPT
Size Port Type
316 Stainless Steel
Part #
Price/E
1/4"
full
DSBV25
$95.50
3/8"
full
DSBV38
95.50
1/2"
full
DSBV50
100.25
3/4"
full
DSBV75
131.50
1"
full
DSBV100
185.25
1¼"
full
DSBV125
234.50
1½"
full
DSBV150
367.50
2"
full
DSBV200
457.00
sliding lock
mechanism
