Valves
P
581 DPL413 877.963.4966 • dixonvalve.com
Safety Vented Ball Valves
Features:
•for air service only
•rated to600 PSI
•Lockable ball valves vent downstream air in accordance with
OSHA regulation 1910.147 for pneumatic systems.
•¼" - ½" full port; ¾" - 2" standard port
•brass valve
•chromium plated ball
•RTFE seats and stuffing box ring
•blow-out proof stem design
•adjustable packing gland
Bronze Ball Valve with NPT Tap for Drain
Brass Ball Valves
Features:
•for air service only
•rated to600 PSI
•½" full port; ¾" - 1" standard port
•brass valve
•chromium plated ball
•RTFE seats and stuffing box ring
•blow-out proof stem design
•adjustable packing gland
female NPT x male NPT
Size Port Type Brass
Part # Price/E
1/2" full BMV50 $41.00
3/4" standard BMV75 65.25
1" standard BMV100 93.00
female NPT x female NPT
Size Port Type Brass
Part # Price/E
1/4" full BBV25LV $49.90
3/8" full BBV38LV 49.90
1/2" full BBV50LV 49.90
3/4" standard BBV75LV 72.00
1" standard BBV100LV 92.00
1-1/4" standard BBV125LV 145.50
1-1/2" standard BBV150LV 178.25
2" standard BBV200LV 216.25
female NPT x female NPT
Features:
•recommended for water and air service
•rated to125 PSI WOG
•brass ball valves vent downstream air in accordance with
OSHA regulations for pneumatic systems
•chromium plated ball
•RTFE seats and stuffing box ring
•blow-out proof stem design
•adjustable packing gland
• full port
•auto-drain / auto-vent
•A ¼" NPT tapped port provides additional options such as
an air venting elbow or noise muffler.
Size Port Type Bronze
Part # Price/E
1/4" full BBV25VT $53.00
3/8" full BBV38VT 53.00
1/2" full BBV50VT 53.00
3/4" full BBV75VT 107.25
1" full BBV100VT 150.00
sliding lock
mechanism
