Valves
DPL413
P
877.963.4966 • dixonvalve.com 582
Carbon Steel Ball Valves
High Pressure Full-Bore Ball Valves
Dual Y Valves
Non-Vented Vented
Features:
•for control of air, water, oil and gas in hose or pipe lines, for
other services, please contact the factory
•rated to150 PSIsaturated steam
•¼" - 1" rated to2000 PSI; 1¼" - 2" rated to 1500 PSI
•carbon steel body
•chromium plated ball
•RPTFE seats and seals
•blow-out proof stem
•adjustable packing gland
•1/4" and 3/8" full port; 1/2" - 2" standard port
Mini Ball Valves
Features:
•rated to450 PSI
•nickel plated brass body
•PTFE seats and Buna-N stem seal
•blow-out proof stem
•1/4" and 3/8" full port; 1/8" and 1/2" standard port
•maximum temperature330°F
•American Gas Association and Canadian Gas Association
approved
Female NPT
Inlet (1)
Female NPT
Outlet (2)
Brass
Part # Price/E
1" ¾" BBV100DW $156.10
1¼" ¾" BBV125DW 156.10
Female NPT
Inlet (1)
Female NPT
Outlet (2)
Brass
Part # Price/E
1" ¾" BBV100DWV $156.10
1¼" ¾" BBV125DWV 156.10
Features:
•dual action valve, ideal for compressor applications
•female NPT threads
•non-vented rated to600 PSI WOG
•vented rated to125 PSI Cold Working Pressure
female NPT x female NPT
Size Port Type Brass
Part # Price/E
1/8" standard MBV12 $13.40
1/4" full MBV25 13.40
3/8" full MBV38 12.45
1/2" standard MBV50 18.30
female NPT x female NPT
Size Port Type Carbon Steel
Part # Price/E
1/4" full IBV25 $61.80
3/8" full IBV38 61.80
1/2" standard IBV50 61.80
3/4" standard IBV75 71.25
1" standard IBV100 95.40
1-1/4" standard IBV125 145.50
1-1/2" standard IBV150 202.00
2" standard IBV200 261.50
Features:
•blow out proof stem
•rugged construction
•Viton®seals
•female thread
•stainless steel valves have Delrin®seats
female NPT x female NPT
Size PSI Carbon Steel PSI 316 Stainless Steel
NPTF Part # Price/E SAE Part # Price/E NPTF Part # Price/E
1/4" 7350 HPBV25 $63.90 HPBV25SAE $71.65 5880 HPBV25SS $427.50
3/8" 7350 HPBV38 67.80 HPBV38SAE 80.70 5880 HPBV38SS 497.50
1/2" 7350 HPBV12 73.70 HPBV12SAE 87.10 5880 HPBV12SS 595.00
3/4" 5880 HPBV34 145.05 HPBV34SAE 162.20 5145 HPBV34SS 1027.90
1" 5145 HPBV10 173.10 HPBV10SAE 190.00 5145 HPBV10SS 1212.80
1¼" 5880 HPBV125 452.90 HPBV125SAE 490.20 --- --- ---
1½" 5880 HPBV150 548.90 HPBV150SAE 583.00 --- --- ---
2" 5880 HPBV200 831.00 HPBV200SAE 870.00 --- --- ---
