Air Fittings
119
DPL413
877.963.4966 • dixonvalve.com
E
King Safety Cables
Application:
•
When hose, couplings or clamps fail, or there is an accidental separation of the assembly, King safety cables minimize
damage to equipment and injuries to operators.
•
King safety cable reaches across the hose fittings to provide standby safety for hose. Spring-loaded loops in the cable
ends open easily to pass over the couplings for a firm grip on the hose.
•
Thoroughly tested with years of service. A positive safeguard for air hose connections - helps you meet today's
safety standards.
King safety cable must be installed in the extended position (no slack).
Features:
•
hose-to-hose or hose-to-rigid outlet
•
King cable is the low cost answer to eliminate injuries
caused by broken air hose connections
•
highly resistant to rust and corrosion
•
no tools needed - easy to install and remove
•
maximum working pressure:
200 PSI
Note: Cables are shipped with safety restraint labels attached. Labels are not pictured.
King Safety Cable Options
Style W, for hose-to-hose service
Style WSR, for hose-to-tool service
correct installation
incorrect installation
hose end
tool end
hose end
hose end
Hose ID
Cable
Length MaximumWorking
Pressure PSI
Steel
Stainless Steel
Part #
Price/E Part #
Price/E
½" - 1¼"
1/8"
20¼"
200
WSR1
$18.45
WSR1SS
$48.25
½" - 2"
3/16"
28"
200
WSR3
26.50
---
---
1½" - 3"
1/4"
38"
200
WSR2
29.10
WSR2SS
101.80
4"
3/8"
44"
200
WSR4
64.40
---
---
Hose ID
Cable
Length MaximumWorking
Pressure PSI
Steel
Stainless Steel
Part #
Price/E Part #
Price/E
½" - 1¼"
1/8"
20¼"
200
WB1
$18.45
WB1SS
$51.05
½" - 2"
3/16"
28"
200
WB3
27.35
---
---
1½" - 3"
1/4"
38"
200
WA2
30.00
WA2SS
107.10
4"
3/8"
44"
200
WA4
64.45
---
---
Hose ID Cable Part #
Description
Max. Work.
Press. PSI Price/E
½" - 1¼" 1/8"
WSR1C
WSR1 with safety clip and lanyard used to lock Air King couplings
200 $32.10
½" - 1¼" 1/8"
WB1C
WB1 with safety clip and lanyard used to lock Air King couplings
200 31.55
½" - 1¼" 1/8"
WSR1E
WSR1 with stainless steel safety marine eye used to connect safety cable to a bolt on tool
200 53.25
1½" - 3" 1/4"
WA2B
WA2 with bronze/copper ferrule for special environmental conditions
200 60.10
WSR1E
WSR1E with stainless steel marine eye
WB1C
WB1 with safety clip and lanyard
•
see page 683 for OSHA regulations
