8D
Polyester Double Jacket Attack Hose
Our National Fire Hose 8D is a municipal grade double jacket hose with a
lightweight EPDM rubber liner that meets all the requirements of NFPA 1961.
It is designed for use as an attack handline hose and is manufactured to a
service test pressure of 400 psi (2760 kPa) to handle all fireground challenges
with ease.
Should one desire an upgraded design with similar materials using a rubber
adhesive, UL or FM certification, or if a woven-in stripe is required for identification
purposes, consider our Ponn Supreme hose found on pages M-6 and M-7.
Properties and Construction
• Exceptional quality, double jacket, rubber lined municipal fire hose made from
100% high tensile strength polyester yarn with a lining of extruded EPDM.
• Optional Dura-Cote TM treatment greatly increases abrasion, heat, flame
and petrochemical resistance while virtually eliminating water pick-up. When
treated, 8D is protected from mildew and no drying is required.
• Hose remains flexible to temperatures as low as -40°F (-40°C) and is highly
resistant to ozone and oxidation.
• National Fire Hose 8D hose is manufactured in accordance with NFPA
1961 standard, latest edition within our ISO-9001: 2000 certified quality
assurance system.
ATTACK
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH SIZE TYPE MATERIAL
Part Number Example: 8D17X50Y15N = 8D Hose, 1-3/4” ID by 50’ Length, Yellow, 1-1/2” Aluminum NH/NST
Threaded Coupling
How to Order
8D 17X50 Y 15 N
8D 10 = 1” 50 = 50’ Y = Yellow 10 = 1” N = NH Blank=
15 = 1-1/2” 100 = 100’ R = Red 15 = 1-1/2” I = IPT Aluminum
17 = 1-3/4” B = Blue 20 = 2”
20 = 2” O = Orange 25 = 2-1/2”
25 = 2-1/2” G = Green 30 = 3”
30 = 3” T = Tan
W = White (Uncoated)
EPDM Rubber Liner
Polyester Inner Jacket
Polyester Outer Jacket
SIZE SERVICE PROOF BURST WEIGHT FLAT HOSE BED BOWL
TEST TEST (For 50’ Coupled) WIDTH Volume (100’) SIZE
Construction:
Polyester Double Jacket
EPDM Rubber Inner Liner
Temperature Range:
-40° to 150°F (-40° to 65°C)
Couplings Available:
Aluminum NH/NST
or IPT Threaded
Hose Colors:
- Type 8D
M-14
PSI (kPa) PSI (kPa) PSI (kPa) LBS (KG) IN FT 3 IN
1” 400 (2760) 800 (5515) 1200 (8275) 13 (5.9) 2.10 1.0 1-1/2
1-1/2” 400 (2760) 800 (5515) 1200 (8275) 16 (7.3) 2.80 1.0 1-15/16
1-3/4” 400 (2760) 800 (5515) 1200 (8275) 17 (7.7) 3.20 1.5 2-3/16
2” 400 (2760) 800 (5515) 1200 (8275) 22 (10) 3.70 1.5 2-1/2
2-1/2” 400 (2760) 800 (5515) 1200 (8275) 28 (12.7) 4.50 2.0 3
3” 400 (2760) 800 (5515) 1200 (8275) 39 (17.7) 5.30 3.0 3-17/32
