8T
Lightweight Polyester Double Jacket Hose
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH SIZE TYPE MATERIAL
Part Number Example: 8T17X50Y15N = 8T Hose, 1-3/4” ID by 50’ Length, Yellow, 1-1/2” Aluminum NH/NST
Threaded Coupling
How to Order
8T 17X50 Y 15 N
8T 15 = 1-1/2” 50 = 50’ Y = Yellow 15 = 1-1/2” N = NH Blank=
17 = 1-3/4” 100 = 100’ R = Red 25 = 2-1/2” I = IPT Aluminum
25 = 2-1/2” B = Blue 30 = 3”
30 = 3” O = Orange
G = Green
T = Tan
W = White
(Uncoated)
Polyurethane Liner
Polyester Inner Jacket
Polyester Outer Jacket
This double jacket municipal grade fire hose incorporates a lightweight
polyurethane liner that meets all the requirements of NFPA 1961. It is designed
for use as an attack handline hose and can be used for potable water transfer
in an emergency.
Should one desire an upgraded design keeping with a polyurethane liner,
or if a woven-in stripe is required for identification purposes, consider our
Ponn Conquest hose found on pages M-4 and M-5.
Properties and Construction
• High quality, double jacket, municipal fire hose made from 100% high
tensile strength polyester yarn along with a lining of thermoplastic
polyurethane for reduced weight while remaining kink resistant.
• Optional Dura-Cote TM protective treatment greatly increases abrasion, heat,
flame and petrochemical resistance while virtually eliminating water pick-up.
When treated, 8T is protected from mildew and no drying is required.
• Hose remains flexible to temperatures as low as -40°F (-40°C) and is
designed to meet all NFPA requirements for ozone resistance.
• Polyurethane lining material meets National Sanitation Foundation (NSF)
Standard 61 for drinking water.
• National Fire Hose 8T hose is manufactured in accordance with NFPA
1961 standard, latest edition within our ISO-9001: 2000 certified quality
assurance system.
Construction:
Polyester Double Jacket
Polyurethane Inner Liner
Temperature Range:
-40° to 150°F (-40° to 65°C)
Couplings Available:
Aluminum NH/NST or
IPT Threaded
Hose Colors:
ATTACK
POTABLE
- Type 8T
M-15
SIZE SERVICE PROOF BURST WEIGHT FLAT HOSE BED BOWL
TEST TEST (For 50’ Coupled) WIDTH Volume (100’) SIZE
PSI (kPa) PSI (kPa) PSI (kPa) LBS (KG) IN FT 3 IN
1-1/2” 400 (2760) 800 (5515) 1200 (8275) 14 (6.4) 2.80 1.0 1-15/16
1-3/4” 400 (2760) 800 (5515) 1200 (8275) 16 (7.3) 3.20 1.0 2-3/16
2-1/2” 400 (2760) 800 (5515) 1200 (8275) 25 (11.3) 4.50 1.5 3
3” 400 (2760) 800 (5515) 1200 (8275) 36 (16.3) 5.25 2.0 3-17/32
