Page 13 - GOODYEAR RUBBER PRODUCTS INC 1-866-711-4673 Snaptite Municipal Fire Hose Catalog

Dura-Pak
Nylon Double Jacket Attack Hose
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH SIZE TYPE MATERIAL
Part Number Example: DP17X50Y15N = DP Dura-Pak Hose, 1-3/4” ID by 50’ Length, Yellow, 1-1/2” Aluminum
NH/NST Threaded Coupling
How to Order
DP 17X50 Y 15 N
DP 15 = 1-1/2” 50 = 50’ Y = Yellow 15 = 1-1/2” N = NH Blank=
17 = 1-3/4” 100 = 100’ R = Red 20 = 2” I = IPT Aluminum
25 = 2-1/2” B = Blue 25 = 2-1/2”
30 = 3” O = Orange 30 = 3”
G = Green
T = Tan
Polyurethane Liner
Nylon Inner Jacket
Nylon Outer Jacket
SIZE SERVICE PROOF BURST WEIGHT FLAT HOSE BED BOWL
TEST TEST (For 50’ Coupled) WIDTH Volume (100’) SIZE
PSI (kPa) PSI (kPa) PSI (kPa) LBS (KG) IN FT 3 IN
1-1/2” 400 (2760) 800 (5515) 1200 (8275) 13 (5.9) 2.80 1.0 1-15/16
1-3/4” 400 (2760) 800 (5515) 1200 (8275) 15 (6.8) 3.20 1.0 2-3/16
2-1/2” 400 (2760) 800 (5515) 1200 (8275) 23 (10.4) 4.50 1.5 3
3” 400 (2760) 800 (5515) 1200 (8275) 31 (14.1) 5.30 2.0 3-17/32
Construction:
Nylon Double Jacket
Polyurethane Inner Liner
Temperature Range:
-40° to 150°F (-40° to 65°C)
Couplings Available:
Aluminum NH/NST
or IPT Threaded
Hose Colors:
ATTACK
HI-RISE
C.A.F.S.
POTABLE
When introduced, Dura-Pak started an industry-wide trend toward lightweight
hi-rise hose. Originally designed for back-pack use, Dura-Pak folds tightly for small
spaces, hose beds and hi-rise packs. Because it is so durable many departments
have selected Dura-Pak for frontline attack duties.
Properties and Construction
• Dura-Pak is a double jacket municipal fire hose with both jackets made from
100% high strength, low stretch, air-entangled nylon along with a lining of
thermoplastic polyurethane for reduced weight while remaining kink resistant.
• Reverse twill weave of the inner jacket provides a smooth waterway, comparable
only to Ponn Conquest.
• Standard Dura-Cote™ protective treatment greatly increases abrasion, heat,
flame and petrochemical resistance while virtually eliminating water pick-up.
When treated, Dura-Pak is protected from mildew and no drying is required.
• Lining remains flexible to temperatures as low as -40°F (-40°C) and is highly
resistant to ozone and oxidation.
• Suitable for C.A.F.S. and foam concentrate applications.
• Polyurethane lining material meets National Sanitation Foundation (NSF)
Standard 61 for drinking water.
• National Fire Hose Dura-Pak is manufactured in accordance with NFPA 1961
standard, latest edition within our ISO-9001: 2000 certified quality assurance
system.
- Type DP
M-13
