Rubber Rectangular Stock
Series 1200
FIGURE 2.5 - Rectangle stock cross-section
Dash No. “A” “B”
0101 .062 .250
0102 .062 .500
0103 .062 .750
0104 .125 .125
0105 .125 .250
0106 .125 .500
0107 .125 .750
0108 .125 1.00
0109 .187 .187
0110 .187 .250
0111 .187 .375
0112 .187 .500
0113 .187 .750
0114 .187 1.00
0115 .250 .250
0116 .250 .375
0117 .250 .500
0118 .250 .750
0119 .250 1.00
0120 .375 .375
0121 .375 .500
0122 .375 .625
0123 .375 .750
0124 .375 1.00
0125 .500 .500
0126 .500 .625
0127 .500 .750
0128 .500 1.00
0129 .625 .625
0130 .625 .750
0131 .625 1.00
0132 .750 .750
0133 .750 1.00
0134 1.00 1.00
0135 1.00 1.25
0136 1.00 1.50
0137 1.00 2.00
0138 1.50 1.50
0139 2.00 2.00
Closed cell sheet is manufactured to
AMS and MIL specification. Density can
be selected to meet specific
requirements for low closure load seals.
36" x 36" and 24" x 24" sheets in 1/16"
though 5/8" thickness standard in red,
and other colors are available upon
request. Most sizes and specifications in
stock for immediate delivery. Several
sizes are available in roll form as well.
FEATURES FOR
SILICONE SPONGE:
•High temperature capability,
standard for silicone
•Easy compressibility for applications
requiring a lower closure sealing force
•Silicone sponge is closed cell,
minimizing water absorption.
AVAILABLE SPECIFICATIONS
AMS 3193, AMS 3194, AMS 3195,
AMS 3196, MIL R 46089,
ASTM D 1056, 2D2, 2D3,
SAE 3195 MIL C 3133, TE 7, TE 12
