The standard manufacturing length is 4 m (13’). Upon request, 6 m length tubes (19’ 8”) can be manufactured.
* Other diameters can also be manufactured. Please consult.
** Pressure data is noted at ambient temperature. Pressure values should be reduced by 20% for each increase of 212°F.
MANUFACTURE:
The
VenaSIL 655
silicone tube complies with FDA 21 CFR
177.2600, USP Class VI, and FDA-BfR Part XV standard in Germany. It
is a platinum-cured high purity tube, manufactured with four polyester
fabric reinforcements and 302 L stainless steel wire spring encased
inside the tube at different levels.
For higher pressure applications, we also offer a reinforced version
(655 MIF).
Inner appearance:
Translucent and smooth.
Outer appearance:
Translucent (standard) or colored (special
order), and smooth.
Applications:
A sturdier, extremely flexible product line, even in
large diameters. Designed for use at specific points where there may
be sudden high pressure surges (hammering). It is the strongest tube
in the VenaSil range.
Silicone material option:
- FDA/ BfR Part XV
- FDA/ BfR Part XV Platinum Cured
- USP Class VI Platinum Cured
4
(mm)
(mm)
(inch)
Inner
Diameter*
Wall
Thickness
(mm) (inch)
Working Pressure**
Theoretical
Outer Diameter
bar @ 20°C
ISO
1402/1994
psi @ 68°F
ISO
1402/1994
Bursting Pressure**
bar @ 20°C
ISO
1402/1994
6 1/4
6,5
19,0 0,75
43
21,0
305
63,0
914
8 5/16
6,5
21,0 0,83
46
19,3
280
58,0
841
10 3/8
6,5
23,0 0,91
49
18,0
261
54,0
783
13 1/2
6,5
26,0 1,02
54
16,3
237
49,0
711
16 5/8
6,5
29,0 1,14
59
15,0
218
45,0
653
19 3/4
6,5
32,0 1,26
68
13,7
198
41,0
595
22 7/8
6,5
35,0 1,38
72
13,3
193
40,0
580
25
1
6,5
38,0 1,50
80
12,3
179
37,0
537
32 1 1/4
6,5
45,0 1,77
100
11,0
160
33,0
479
38 1 1/2
7
52,0 2,05
121
10,0
145
30,0
435
51
2
7
65,0 2,56
185
8,0
116
24,0
348
63 2 1/2
7
77,0 3,03
273
6,7
97
20,0
290
76
3
7
90,0 3,54
318
5,7
82
17,0
247
102 4
7
116,0 4,57
423
4,0
58
12,0
174
psi @ 68°F
ISO
1402/1994
Bending
Radius
(mm)
ISO
1746/1983
684 Torr (mmHg)
0,91 bar
0,90 atm
9,29 mH2O
13,23 psi
26,93 inHg
Vacuum
tolerance
