929BJ Silicone Jacketed PTFE Hose with
Static-Dissipative Tube
Exceeds SAE 100R14B Performance
929BJ
Part
Number
Hose
I. D.
Max.
Hose
O. D.
Tube
Wall
Max.
Working
Pressure
Min.
Bend
Radius
Vacuum
Rating
Weight
Crimp
Fitting
80C
Crimp
Die
hose
inch mm inch mm inch wpsi
MPa inch mm inch/Hg.
lbs/ft
kg/m series
pg
crimp die
929BJ-4
3/16
5
0.58
15
.040 3000 21
2.0
51
28
.17
25.3 91N 150-164
T04J
929BJ-5 (+)
1/4 6.3 0.63
16
.040 2500 17
2.0
51
28
.194 28.9 91N 150-164
T05J
929BJ-6
5/16
8
0.69
18
.040 2500 17
4.0
102
28
.232 34.5 91N 150-164
T06J
929BJ-8
13/32 10 0.79
20
.042 2000 14
4.6
117
28
.288 42.9 91N 150-164
T08J
929BJ-12
5/8
16 1.04
26
.042 1200 8
6.5
165
12
.403 60.0 91N 150-164
T12J
929BJ-16
7/8
22 1.36
35
.042 1250 9
7.4
188
14
.782 116.4 91N 150-164 T16HJ
(+) Non Standard. See page ii for information on non-standard products.
Tube:
Black Static-Dissipative PTFE
Reinforcement:
304 Stainless Steel
Cover:
Brown Silicone Jacket
Temperature:
-65°F to +450°F
-54°C to +232°C
Change in length at working pressure is +2% to -4%.
Min. Burst Pressure is 4x Max. Working Pressure
Applications:
• Vacuum lines for high temperature autoclaves
• Tough smooth bore hose applications requiring any or all of
these special features.
Special Features:
• Silicone jacket protects stainless steel wire reinforcement
against wear and fraying even at temperatures up to 450F.
• Silicone jacket provides clean smooth cover and prevents
contaminants from accumulating in braided reinforcement.
• Steam Cleanable
• Tighter bend radius
• Better kink resistance
• Enhanced resistance to gas permeation
• Cover must be skived prior to fitting attachment
